STF-Multi axis Series Hardware Manual
Power
Type
Supply
STF05-2XU-ECX
STF10-2XU-ECX
STF05-2XU-ECX-S
STF10-2XU-ECX-S
STF05-4X-ECX
STF10-4X-ECX
24-70VDC
STF05-4X-ECX-S
STF10-4X-ECX-S
STF05-4XU-ECX
STF10-4XU-ECX
STF05-4XU-ECX-S
STF10-4XU-ECX-S
400-820-9661
Output
Input
Current
2x2 optical isolated digital
2x5A max
2x3 optical output:
isolation input
(peak of sin)
2x1 Brake direct
drive,control signal output
2x2 optical isolated digital
2x10A max
2x3 optical output:
isolation input
(peak of sin)
2x1 Brake direct
drive,control signal output
2x2 optical isolated digital
2x6A max
2x3 optical output:
isolation input
(peak of sin)
2x1 Brake direct
drive,control signal outpu
2x2 optical isolated digital
2x10A max
2x3 optical output:
isolation input
(peak of sin)
2x1 Brake direct
drive,control signal outpu
4x3 optical isolated digital
4x6A max
4x5 optical output:
isolation input
(peak of sin)
4x1 Brake direct
drive,control signal output
4x3 optical isolated digital
4x10A max
4x5 optical output:
isolation input
(peak of sin)
4x1 Brake direct
drive,control signal output
4x3 optical isolated digital
4x6A max
4x5 optical output:
isolation input
(peak of sin)
4x1 Brake direct
drive,control signal output
4x3 optical isolated digital
4x10A max
4x5 optical output:
isolation input
(peak of sin)
4x1 Brake direct
drive,control signal output
4x2 optical isolated digital
4x6A max
4x3 optical output:
isolation input
(peak of sin)
4x1: Brake direct drive
control signal output
4x2optical isolated digital
4x10A max
4x3 optical output:
isolation input
(peak of sin)
4x1: Brake direct drive
control signal output
4x2 optical isolated digital
4x6A max
4x3 optical output:
isolation input
(peak of sin)
4x1: Brake direct drive
control signal output
4x2 optical isolated digital
4x10A max
4x3 optical output:
isolation input
(peak of sin)
4x1: Brake direct drive
control signal output
5
Output Communication
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
EtherCAT
Configuration
STO
Port
USB Type-C NO
USB Type-C NO
USB Type-C Support
USB Type-C Support
USB mini-B NO
USB mini-B NO
USB mini-B Support
USB mini-B Support
USB Type-C NO
USB Type-C NO
USB Type-C Support
USB Type-C Support
Version 1.0
11/14/2023
