STF-Multi axis Series Hardware Manual
• Output current:
STF05-2XU Continuous output current 2x5A
STF10-2XU Continuous output current 2x10A
STF05-4X/4XU Continuous output current 4x5A
STF10-4X/4XU Continuous output current 4x10A
• I/O
STF05/10-2XU/4XU:
3 optically isolated input,5~24V
1 optically isolation digital output: maximum withstand voltage 30V, maximum output current
100mA
1 brake direct drive control signal output: maximum withstand voltage 24V, maximum current
1A
STF05/10-4X:
5 optically isolated digital signal input,5~24V
2 optically isolation of digital signal output: maximum withstand voltage 30V, maximum output
current 100mA
1 brake direct drive control signal output: maximum withstand voltage 24V, maximum current
1A
• Digital, red and green LED display
• STO function (optional)
