6.5 Configuring the air handling unit

Further information on this can be found in the X-
CUBE Control 2 operating instructions.

6.5.1 Setting up network communication

Personnel:
HVAC technician

If you want to use a PC to communicate with the air
handling unit you have to set up the network connec-
tion. The following steps apply to a Windows PC.
1. On the desktop, select 'Start è Control Panel
è Network and Internet
è Network and Sharing Center' .
Fig. 33: Setting up a new connection or network
2. Select 'Set up a new connection or network'
( Fig. 33 /1).
ð The 'Set up a connection or network' window
opens.
Fig. 34: Setting up a new network
3. Select 'Set up a new network' ( Fig. 34 /1), then
click 'Next' ( Fig. 34 /2).
Configuring the air handling unit > Setting up network communication
4.
Fig. 35: LAN connection status
5.
Air handling unit X-CUBE X2 compact 2
Initial commissioning
ð The software searches for an access point.
Select the air handling unit.
ð The 'Local Area Connection Status' window
opens.
Select 'Properties' ( Fig. 35 /1).
ð The 'Local Area Connection Properties'
window opens.
53
