Page 1 Transportation and installation manual GB/en Air handling unit X-CUBE compact including X-CUBE compact accessories Read the instructions prior to performing any task!
Page 2 TROX GmbH Heinrich-Trox-Platz 47504 Neukirchen-Vluyn Germany Telephone: +49 2845 202-0 Fax: +49 2845 202-265 E-mail: trox@trox.de Internet: www.troxtechnik.com A00000052582, 1, GB/en 01/2016 © TROX GmbH 2015 Air handling unit X-CUBE compact...
Page 3 The Delivery and Payment Terms of TROX GmbH are available at www.troxtechnik.com. Other applicable documentation In addition to these instructions, the following docu- ments apply: Order confirmation  Air handling unit data sheet from TROX GmbH  Product drawings  Air handling unit X-CUBE compact...
Page 4 Additional drawings, if applicable  and hence facilitate following the instructions. The Operating manual for X-CUBE compact above listed signal words will be used.  Installation and commissioning manual for the X- ...
Page 5: Table Of Contents
F Circuit diagram tray 400 V AC-PHE..... 92 4.4.1 Setting up air handling unit/AHU compo- G Circuit diagram tray 400 V AC-RHE..106 nents............18 H Accessories for X-CUBE compact..... 120 4.4.2 Before installation........19 4.4.3 Assembling AHU components....20 4.4.4 Installing accessories......23 Installation............
Page 6: Overview
Fig. 1: Overview with rotary heat exchanger Multileaf dampers Multileaf dampers Centrifugal fan Filter unit Rotary heat exchanger Exhaust air (EHA) Instrumentation and control systems (I&C) Extract air (ETA) Filter unit Supply air (SUP) Centrifugal fan Fresh air (ODA) Air handling unit X-CUBE compact...
Page 7 Each X-CUBE compact air handling unit consists of several components. The table below ( on page 7) contains the AHU components that can make up the air handling unit. The components and quantities actually used for the air handling unit are listed in the order-specific X-CUBE compact operating manual. AHU components...
Page 8: Safety
Air handling unit X-CUBE compact...
Page 9: Personal Protective Equipment
Safety harnesses must only be used by personnel who have been specifically trained to use them. Air handling unit X-CUBE compact...
Page 10: Transport And Storage
Report the damage to TROX immediately in writing. Fig. 3: Lashing point  Note that shipping damage must be reported within  The lashing point on the means of transport must be four days of delivery. attached centrally to the packaging unit. Air handling unit X-CUBE compact...
Page 11: Transporting Packages
When transporting packages by crane, attach the crane hook so that it is located above the centre of gravity of the packages – Lift the packages carefully and watch whether they tilt If required, change attachment Air handling unit X-CUBE compact...
Page 12: Transporting Packages By Forklift Or Pallet Truck
Ensure that an eccentric centre of gravity will not Protective clothing  cause the AHU component to tip. Hearing protection  Slowly lift the AHU component and begin trans- Safety shoes  portation. Protective gloves  Air handling unit X-CUBE compact...
Page 13 Ensure that the AHU component is not damaged by the chains or ropes. Align the attachment with the centre of gravity to ensure a symmetrical load distribution. Slowly lift the AHU component and begin trans- portation. Air handling unit X-CUBE compact...
Page 14 Screw all beckets or ring nuts (Fig. 8/1) fully into all threaded holes. Hook the cross members (Fig. 8/3) into the beckets or ring nuts. Connect the cross members with chains (Fig. 8/2). Air handling unit X-CUBE compact...
Page 15: Storing Packages
Follow these accord- ingly. 3.5 Unpacking packages Only dispose of packaging shortly before installation if Ä Chapter 3.2 ‘Delivery there is no transport damage, check’ on page 10. Air handling unit X-CUBE compact...
Page 16: Installation And Assembly
The room is:  – clean – – free from conductive dust particles – free from strong electromagnetic fields – free from aggressive media – free from frost, and – fitted with a correctly functioning drainage system Air handling unit X-CUBE compact...
Page 17: Requirements For Outdoor Installation
AHU components are precisely aligned is L/500 (L = support length). A maximum deflection (movement of doors, proper sealing at connections) under load of 10 mm must not be exceeded Air handling unit X-CUBE compact...
Page 18: Insulating The Air Handling Unit From Vibrations
TROX) must be compared and the required meas- ures must be determined by an acoustician. Splitter sound attenuators can be used for sound insulation purposes if applicable. Air handling unit X-CUBE compact...
Page 19: Before Installation
Ä ‘Assembling AHU components in the Deformed seals return to their original form approx. outdoor area’ on page 20. 60 min after the transport fastenings have been removed. Assemble the AHU components as close together as possible. Air handling unit X-CUBE compact...
Page 20: Assembling Ahu Components
Fig. 13: Aligning AHU components Align the AHU components so that they are flush with one another (Fig. 13/1). Roof installation Attach ring seals to the four cylinder screws. Fig. 14: Roof supports Air handling unit X-CUBE compact...
Page 21 Fig. 16: Attaching plugs Seal the transport openings in the base of the air handling unit with the plugs (Fig. 16/1) provided. ð This prevents water from getting into outdoor units. Air handling unit X-CUBE compact...
Page 22 Fix the air ducts to the air handling unit without exercising any tension. Isolate air ducts with spigots or profile frames. Isolate the air ducts with spigots or profile frames correctly and protect from weather. Air handling unit X-CUBE compact...
Page 23: Installing Accessories
Fig. 20: Gusset plates Screw two standard gusset plates (Fig. 20/1) to the upper unit holes using the screws provided. Screw two gusset plates with cut-out (Fig. 20/2) to the lower unit holes using the screws provided. Air handling unit X-CUBE compact...
Page 24 Attach the seal (Fig. 23/1) between the roof (Fig. 23/2) and the accessory module (Fig. 23/4). Screw the roof (Fig. 23/2) of the accessory module (Fig. 23/4) onto the accessory module (Fig. 23/4) using the four screws (Fig. 23/3). Air handling unit X-CUBE compact...
Page 25: Installation
– Ensure that other units/systems are properly connected to the air handling unit. – The operator/system manufacturer is respon- sible for planning and installing the additional safety equipment. Air handling unit X-CUBE compact...
Page 26: Changing Operating Side
Press in the clamping rails (Fig. 27/1). wards. Fix the right and left inspection access panels on Disconnect the plug connections on the inside of the rear side using the compression twist locks. the inspection access panels. Air handling unit X-CUBE compact...
Page 27: Connecting Siphon To Air Handling Unit
This can also damage the air handling unit. – Lay drainage pipes in such a way that they cannot be mechanically or thermally destroyed Fig. 30: Siphon for positive pressure use Air handling unit X-CUBE compact...
Page 28: Connecting The Heater/Cooler
There are stickers on the connection side of the Connect the siphons to the condensate drains heat exchangers that indicate the feed (Fig. 32/IN) (Fig. 31/1). and return flow connections (Fig. 32/OUT) in the counterflow principle. Connect the siphons to the sewage system. Air handling unit X-CUBE compact...
Page 29: Connecting The Air Handling Unit To Power Supply
EN 60204 (VDE 0113) with due regard to the required safety precautions. Connect the heat exchanger to the on-site con- nection whilst permanently holding up the thread connection using a hexagon spanner (Fig. 33/1). Air handling unit X-CUBE compact...
Page 30: Connecting The Air Handling Unit To The Building
BMS or CTS system. Furthermore, the installed I&C can be networked with the following bus systems: Modbus RTU  Modbus TCP/IP  Internal web server  BACnet  LON (accessory – subject to charge)  Air handling unit X-CUBE compact...
Page 31: Initial Commissioning
– Be careful when working on these components. – Wear protective gloves, safety shoes and a hard hat. Air handling unit X-CUBE compact...
Page 32: Installing Ahu Components
Clean the air handling unit and ventilation ducts before installing filters above class F9. Clear dust from parts in front of the filter unit in the airflow direction. Air handling unit X-CUBE compact...
Page 33: Multileaf Dampers
TROX cannot guarantee leak-free dampers if the Ventilate the heating coil/cooling coil by opening actuators are provided and installed by others. the upper spigot and the separate ventilation screw. Air handling unit X-CUBE compact...
Page 34: Rotary Heat Exchanger
Never operate damaged rotary heat exchangers – Switch off the air handling unit before working on moving rotary heat exchanger parts and secure the unit against restarting. Wait until all parts have come to a stop. Air handling unit X-CUBE compact...
Page 35: Droplet Eliminator
During readjustment, check that the rotor turns smoothly and is not blocked. Avoid direct grinding, even under operating pressures. The required starting torques must not be exceeded. ð The rotary heat exchanger is set up. Air handling unit X-CUBE compact...
Page 36: Plate Heat Exchanger
Ä Appendix ‘Accessories for X-CUBE compact’ on page 120. Ä Appendix Establish bus communication, see ‘Accessories for X-CUBE compact’ on page 120. 6.4 Switching on the air handling unit 6.4.1 Before switching on After transportation, assembly and installation, the fol-...
Page 37: Configuring The Air Handling Unit
On the hand-held control, call up the ‘Technician è Language è Select language’ window. Select the language. Fig. 36: Internet connection On the hand-held control, call up the ‘User è Internet è Internet connection’ window. Air handling unit X-CUBE compact...
Page 38: Setting Up Network Communication
Highlight ‘Set up a new network’ (Fig. 38/1) and click ‘Next’ (Fig. 38/2) to select it. ð The PC searches for an access point. Select the air handling unit. ð The ‘Local Area Connection Status’ window opens. Fig. 40: Local area connection properties Air handling unit X-CUBE compact...
Page 39: Logging In To The Web Server
Select the ‘Login’ (Fig. 42/2) button. ð The air handling unit is connected and can be operated via the web browser. ð The user is logged in to the web server. Restart the PC if necessary. Air handling unit X-CUBE compact...
Page 40: Removal And Disposal
When transporting packages by crane, attach the crane hook so that it is located above the centre of gravity of the packages – Lift the packages carefully and watch whether they tilt. If required, change attachment. Air handling unit X-CUBE compact...
Page 41: Removal
Establish voltage-free state. Empty media. Dispose of media correctly. Disconnect media lines. Loosen unit connections from components to the connection points (module connectors and base frame connectors). Remove individual unit components. Properly remove the unit components. Air handling unit X-CUBE compact...
Page 42: Faq
All technical data relating to the unit can be found in dling unit with regard to its dimensions, weight specifi- the "Operating manual – X-CUBE compact air han- cations, divisibility and technical output data? dling units" in Chapter 10 Technical data.
Page 43 CUBE compact air handling unit" in the chapter "Changing the actuator on the bypass damper for units with a plate heat exchanger". See (Ä X-CUBE compact operating manual). Is a separate supply voltage required for the acces- Yes, a supply voltage of 230 VAC is required.
Page 44 Which communication interfaces are available on the TCP/IP BACnet, Modbus and Modbus RTU communi- air handling unit? cation interfaces are available. A LON communication interface can be established using an additional module (subject to charge). Air handling unit X-CUBE compact...
Page 45: Index
Removal and disposal..........41 Removing Improper transport............11 Noise insulating connectors........22 Initial commissioning..........31 Requirements Droplet eliminator..........35 Initial commissioning..........31 Filter unit............... 32 Installation............19, 25 Heating coil/cooling coil......... 33 Switching on............36 Multileaf dampers..........33 Air handling unit X-CUBE compact...
Page 46 Setting up X-CUBE controller communication... 37 Units for indoor installation........13 Sound insulation............18 Transport damage............10 Storing................ 15 Switching on............... 36 Unpacking..............15 Symbols............... 4 On the packaging..........10 X-CUBE compact components........6 Transport............... 10 X-CUBE compact elements......... 6 Air handling unit X-CUBE compact...
Page 47: Appendix
Appendix Appendix Air handling unit X-CUBE compact...
Page 48 Appendix Air handling unit X-CUBE compact...
Page 49: A Aligning Storage Mass
Aligning storage mass Aligning storage mass Air handling unit X-CUBE compact...
Page 50 ·KLINGENBURG Montageanleitung Mounting Instructions Ausrichtung der Speichermasse Adjustment of storage mass...
Page 51 Um die Speichermasse auf der Antriebswelle zu justieren, müssen auf beiden Seiten des Rotors die Staubdeckel ent- fernt werden. To reposition the the matrix on the drive shaft, on both sides of the rotor the hub caps have to be removed. Der Staubdeckel besteht aus zwei Teilen und ist mit je 2 Schrauben befestigt, welche mit einem Imbusschlüssel (Größe 2,5) zu lösen sind.
Page 52 Dazu alle 4 Schrauben lösen. For this, loosen all 4 screws. Die beiden Stauddeckelteile entfernen. Der Lagerbereich liegt nun offen. Dieser Vorgang ist auf der gegenüberlie- genden Seite des Rotors zu wiederholen. Remove both parts of the hub cap. The bearings are now accessible.
Page 53 Beide Mardenschrauben (1) und (2) am Lager lösen. Dieses auch auf der gegenüberliegenden Seite des Rotors wiederholen. Loosen both set screws, (1) and (2). Repeat this procedure on the opposite side of the rotor. Nun kann die Speichermasse auf der Welle entsprechend Now the matrix can be moved on the shaft.
Page 54 Klingenburg GmbH Boystraße 115 45968 Gladbeck GERMANY Tel. +49 (0) 20 43 / 96 36 - 0 +49 (0) 20 43 / 7 23 62 e-mail: klingenburg@klingenburg.de web: www.klingenburg.de Klingenburg International sp. z o.o. ul. Metalowców 5 58-100 Swidnica POLAND Tel.: +48 (0) 74 / 851 54 00 Fax:...
Page 55: B Motor Drive For Rotary Heat Exchanger
Motor drive for rotary heat exchanger Motor drive for rotary heat exchanger Air handling unit X-CUBE compact...
Page 56 ·KLINGENBURG Assembly instructions Belt Drive for Rotary Heat Exchangers Round Belting...
Page 57 Assembling a round belt for the motor drive Preparation Length of the drive belt: Circumference of the storage mass + 20 mm: (diameter of the storage mass x 3.14) + 20 mm Fix the loose round belt to the circumference of the storage mass.
Page 58 Assembling a round belt for the motor drive Connect the ends of the round belt to the plug-in connector. Completely sealed drive belt. Check the tension of the drive belt.
Page 59 Assembling a round belt for the motor drive Connect the motor belt to the motor’s belt pulley.. The tension of the drive belt must be checked after 400 operating hours (see page 3) and, if necessary, readjusted by shortening.
Page 60 Assembling a round belt for the motor drive Note...
Page 61: C Anti-Frost Heating For Siphons
Anti-frost heating for siphons Anti-frost heating for siphons Air handling unit X-CUBE compact...
Page 64: D Circuit Diagram Tray 230 V Ac-Phe
Circuit diagram tray 230 V AC-PHE Circuit diagram tray 230 V AC-PHE Air handling unit X-CUBE compact...
Page 74 Terminal strip designation Desti- Desti- nation nation Function main supply PE main supply L1 main supply N Einspeisung N voltage supply fresh air motor L1 voltage supply extracted motor L1 voltage supply fresh air motor N voltage supply extracted motor N 4.33:69 voltage supply fresh air motor PE 5.33:69...
Page 75 Klemmleistenbezeichnung Ziel- Ziel- bezeich- bezeich- nung nung Funktionstexte Seite/ Pfad BMS-/smoke-/fire dampershutt off extern on smoke extraction to revolve fast set point shift CO2 Sensor +24V room temperature out side temperature status signal on Betriebsmeldung A-alarm A-Alarm...
Page 78: E Circuit Diagram Tray 230 V Ac-Rhe
Circuit diagram tray 230 V AC-RHE Circuit diagram tray 230 V AC-RHE Air handling unit X-CUBE compact...
Page 88 Terminal strip designation Desti- Desti- nation nation Function main supply PE main supply L1 main supply N voltage supply fresh air motor L1 voltage supply extracted air motor L1 voltage supply fresh air motor N voltage supply extracted air motor N 1.108:83 voltage supply fresh air motor PE 1.112:83...
Page 89 Klemmleistenbezeichnung Ziel- Ziel- bezeich- bezeich- nung nung Funktionstexte Seite/ Pfad BMS-/smoke-/fire dampershutt off extern on smoke extraction to revolve fast set point shift CO2 sensor +24V room temperature out side temperature status signal on Betriebsmeldung A-alarm A-Alarm...
Page 92: F Circuit Diagram Tray 400 V Ac-Phe
Circuit diagram tray 400 V AC-PHE Circuit diagram tray 400 V AC-PHE Air handling unit X-CUBE compact...
Page 102 Terminal strip designation Desti- Desti- nation nation Function main supply PE main supply L1 main supply L2 main supply L3 main supply N voltage supply fresh air motor L1 voltage supply extracted motor L1 voltage supply fresh air motor L2 voltage supply extracted motor L2 voltage supply fresh air motor L3 voltage supply extracted motor L3...
Page 103 Klemmleistenbezeichnung Ziel- Ziel- bezeich- bezeich- nung nung Funktionstexte Seite/ Pfad BMS-/smoke-/fire dampershutt off extern on smoke extraction to revolve fast set point shift CO2 Sensor +24V room temperature out side temperature status signal on A-alarm A-Alarm...
Page 106: G Circuit Diagram Tray 400 V Ac-Rhe
Circuit diagram tray 400 V AC-RHE Circuit diagram tray 400 V AC-RHE Air handling unit X-CUBE compact...
Page 116 Terminal strip designation Desti- Desti- nation nation Function main supply PE main supply L1 main supply L2 main supply L3 Einspeisung N voltage supply fresh air motor L1 voltage supply extracted air motor L1 voltage supply fresh air motor L2 voltage supply extracted air motor L2 voltage supply fresh air motor L3 voltage supply extracted air motor L3...
Page 117 Klemmleistenbezeichnung Ziel- Ziel- bezeich- bezeich- nung nung Funktionstexte Seite/ Pfad BMS-/smoke-/fire dampershutt off extern on smoke extraction to revolve fast set point shift CO2 Sensor +24V room temperature out side temperature status signal on Betriebsmeldung A-alarm A-Alarm...
Page 120: H Accessories For X-Cube Compact
Accessories for X-CUBE compact Accessories for X-CUBE compact Installation and commissioning manual GB/en Accessories for X-CUBE compact units Read the instructions prior to performing any task! Air handling unit X-CUBE compact...
Page 121 Accessories for X-CUBE compact TROX GmbH Heinrich-Trox-Platz 47504 Neukirchen-Vluyn Germany Telephone: +49 2845 202-0 Fax: +49 2845 202-265 E-mail: trox@trox.de Internet: www.troxtechnik.com A00000052545, 2, GB/en 11/2015 © TROX GmbH 2015 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 122 XCC-CD-RA........... 12 XCC-CD-RD.......... 13 XCC-HM..........14 XCC-CM..........16 XCC-HCM..........18 XCC-EHD for R/1300, R/2000 and P/1230........... 20 XCC-EHD for R/3000, R/4200, R/5250, P/1800, P/2400 and P/3600....22 XCC-CPC..........24 XCC-LON..........25 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 123: Overview
Overview Accessories Overview 1.1 Compact units and standard components Image Code Description X-CUBE-C- X-CUBE compact with counter flow plate heat exchanger R(L)-P/xxxx X-CUBE-C- X-CUBE compact with rotary heat exchanger R(L)-R/xxxx XCC-ST Hand-held control unit Modbus connecting cable (RJ12) 1.2 Accessories...
Page 124 Control panel, analog XCC-CD-RD Control panel, digital XCC-S-... Sensor XCC-S-TD: Temperature sensor for ventilation ducts  XCC-S-CO2VOCD: Combined CO / VOC sensor for ventilation  ducts XCC-S-TCO2HR: Room temperature, CO  (shown) Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 125 Accessories Image Code Description XCC-LON LON gateway XCC-CPC Parts kit for pressure-based control (constant pressure) XCC-P Circulator pump XCC-V Valve assembly for the hydraulic connection of heating and/or cooling coils Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 126: Setting The Bus Address For Accessories
Constant pressure control XCC-CPC 0 (supply air), 1 (extract air) – Digital control panel XCC-CD-RD is addressed using the control – panel itself, see connection dia- gram Ä 13 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 127: Establishing The Bus Communication
Establishing the bus com- Connecting the bus cable to the compact unit and to an accessory munication Personnel: Cable entries on the X-CUBE compact Skilled qualified electrician  DANGER! For wiring the components, comply with the requirements and safety notes in the 'X- CUBE compact transport and installation manual'.
Page 128 Mount the electrical connections panel (Fig. 5/1). Fig. 5: Removing the electrical connections panel Loosen the screws (Fig. 5/2) on the electrical con- nections panel (Fig. 5/1) and remove the panel. Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 129 Fig. 9: Message displayed on the hand-held control unit ð Use the hand-held control unit to activate accessories. For details on using the hand- held control unit, refer to the X-CUBE compact operating manual. Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 130: Deactivating Accessories
Use the hand-held control unit to deactivate accesso- ries. For details on using the hand-held control unit, To return to the previous (higher) menu level, refer to the X-CUBE compact operating manual. press Esc. Fig. 10: Service main menu Use the selector on the hand-held control unit to navigate to Service (Fig.
Page 131: Connection Diagrams
Accessories for X-CUBE compact Connection diagrams XCC-CD-RA Connection diagrams 5.1 XCC-CD-RA Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 132: Xcc-Cd-Rd
Accessories for X-CUBE compact Connection diagrams XCC-CD-RD 5.2 XCC-CD-RD Wiring Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 133: Xcc-Hm
Accessories for X-CUBE compact Connection diagrams XCC-HM 5.3 XCC-HM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 134 Accessories for X-CUBE compact Connection diagrams XCC-HM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 135: Xcc-Cm
Accessories for X-CUBE compact Connection diagrams XCC-CM 5.4 XCC-CM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 136 Accessories for X-CUBE compact Connection diagrams XCC-CM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 137: Xcc-Hcm
Accessories for X-CUBE compact Connection diagrams XCC-HCM 5.5 XCC-HCM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 138 Accessories for X-CUBE compact Connection diagrams XCC-HCM Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 139: Xcc-Ehd For R/1300, R/2000 And P/1230
Accessories for X-CUBE compact Connection diagrams XCC-EHD for R/1300, R/2000 and P/1230 5.6 XCC-EHD for R/1300, R/2000 and P/1230 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 140 Accessories for X-CUBE compact Connection diagrams XCC-EHD for R/1300, R/2000 and P/1230 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 141: Xcc-Ehd For R/3000, R/4200, R/5250, P/1800, P/2400 And P/3600
Accessories for X-CUBE compact Connection diagrams XCC-EHD for R/3000, R/4200, R/5250, P/... 5.7 XCC-EHD for R/3000, R/4200, R/5250, P/1800, P/2400 and P/3600 Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 142 Accessories for X-CUBE compact Connection diagrams XCC-EHD for R/3000, R/4200, R/5250, P/... Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 143: Xcc-Cpc
Accessories for X-CUBE compact Connection diagrams XCC-CPC 5.8 XCC-CPC Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 144: Xcc-Lon
Accessories for X-CUBE compact Connection diagrams XCC-LON 5.9 XCC-LON Accessories for X-CUBE compact units Air handling unit X-CUBE compact...
Page 145 Air handling unit X-CUBE compact...
Page 146 Air handling unit X-CUBE compact...
Page 147 Air handling unit X-CUBE compact...
Page 148 TROX GmbH +49 2845 202-0 Heinrich-Trox-Platz +49 2845 202-265 47504 Neukirchen-Vluyn E-mail: trox@trox.de © TROX GmbH 2015 Germany www.troxtechnik.com...
