Summary of Contents for Effekta THOR 31

  • Page 2 All rights reserved. The information in this document is subject to change without notice. Publish statement Thank you for purchasing this series UPS. This series UPS is an intelligent, three phase in phase out, high frequency online single UPS designed by our R&D team who is with years of designing experiences on UPS. With excellent electrical performance, perfect intelligent monitoring and network functions, smart appearance, complying with EMC and safety standards, The UPS meets the world’s advanced level.

  • Page 3: Table Of Contents

    Contents Safety ........................2 1.1 Safety notes ..........................2 1.2 Symbols used in this guide ....................2 Main Features ......................3 2.1 Summarization ......................... 3 2.2 Functions and Features ......................3 Installation ........................4 3.1 Unpack checking........................4 3.2 Cabinet Outlook ........................4 3.3 UPS module appearance ......................

  • Page 4: Safety

    Safety Important safety instructions – Save these instructions There exists dangerous voltage and high temperature inside the UPS. During the installation, operation and maintenance, please abide the local safety instructions and relative laws, otherwise it will result in personnel injury or equipment damage. Safety instructions in this manual act as a supplementary for the local safety instructions.

  • Page 5: Main Features

    Main Features 2.1 Summarization Our UPS is a kind of three-in- single -out high frequency online UPS, it provides three specifications: The 6-50kVA. The products are modularized and adopt the N+X redundancy. It can flexibly increase the number of the UPS modules according to the load capacity which is convenient for flexible allocation and gradually investment.

  • Page 6: Installation

    Automatic charge current adjustment according to battery capacity connected. ◆ 3-Stage intelligent charging ◆ Touch-screen Super-large LCD display (Optional) ◆ Each module with individual LCD display ◆ Remote monitoring via SNMP ◆ Optional Accessories available such as Isolation transformer, Distribution Panel, SNMP ◆...
  • Page 7 30/50kVA Front View(internal) 30/50kVA Rear View(terminal block without cover) 30/50kVA Terminal Block of the cabinet（terminal block without cover） （6）Main Switch of Central Monitor Unit （7）LED display of Central Monitor Unit （8）UPS Module 1 （9）UPS Module 2（10）UPS Module 3（11）UPS Module 4（12）UPS Module 5 （13） Maintenance switch cover（14）Maintenance switch （15）...
  • Page 8 45kVA Front View(internal) 45kVA Rear View(terminal block without cover) 45kVA Terminal Block of the cabinet（terminal block without cover） （6）Main Switch of Central Monitor Unit （7）LED display of Central Monitor Unit （8）module cover （9）UPS Module 1（10）UPS Module 2（11）UPS Module 3（12）UPS Module 4 （13） Maintenance switch cover（14）Maintenance switch （15）...

  • Page 9: Ups Module Appearance

    3.3 UPS module appearance Front View Rear View Side View （1）handle （2）screw holes （3）module connector slot （4）fan （5）UPS Module input switch （6）UPS Module bypass switch 3.4 UPS Module LCD control panel LCD control panel introduction （1）LED（from top to bottom: “alarm”, “bypass output”, “battery output”, “mains output”） （2）LCD display （3）scroll button （4）Off button （5）On button (battery cold start switch)

  • Page 10: External Protective Devices

    The environment temperature around UPS should keep in a range of 0℃～40℃. If the ◆ environment temperature exceeds 40℃, the rated load capacity should be reduced by 12％ per 5℃. The max temperature can't be higher than 50℃. If the UPS is dismantled under low temperature, it might be in a condensing condition. ◆...

  • Page 11: Power Cables

    Power Cables The cable design shall comply with the voltages and currents provided in this section, ◆ Kindly follow local wiring practices and take into consideration the environmental conditions (temperature and physical support media) WARNING！ UPON STARTING, PLEASE ENSURE THAT YOU ARE AWARE OF THE LOCATION AND OPERATION OF THE EXTERNAL ISOLATORS WHICH ARE CONNECTED TO THE UPS INPUT/BYPASS SUPPLY OF THE MAINS DISTRIBUTION PANEL.CHECK TO SEE IF THESE SUPPLIES ARE...

  • Page 12: Battery Connection

    Warning！ In separate bypass connection, the power distribution copper strip between bypass input and AC input must be removed. The AC input and bypass input must be connected to the same neutral. Choose appropriate power cable.（Refer to the table above）and pay attention to the diameter of the connection terminal of the cable that should be greater than or equal to that of the connection poles.
  • Page 13 15kVA module Note: The BAT+ of the UPS connect poles is connected to the anode of the positive battery, the BAT- is connected to the cathode of the positive battery and the anode of the negative battery, the BAT- is connected to the cathode of the negative battery. 6kVA/10kVA modules(30-50kVA) :Factory default setting for battery quantity is 16pcs and for battery capacity is 40AH (charger current 6A).

  • Page 14: Online Ups Modules Replacement

    3.10 Online UPS Modules Replacement For the UPS, modules must be inserted to make a complete UPS system. The replacement of UPS module is very simple and can be operated online. The control system of the UPS can detect the inserted or removed module(s) automatically. The user may operate easily by following the steps mentioned below.

  • Page 15: Parallel System Installation

    Parallel system installation 3.11 The basic installation procedure of a parallel system comprising two or more UPS is the same as that of single. The following sections introduce the installation procedures specified to the parallel system. 3.11.1 Cabinet installation Connect all the UPS needed to be put into parallel system as below picture. (Make sure each UPS input breaker is in “off”...

  • Page 16: Operation

    4. Operation 4.1 Operation Modes The UPS is a double-conversion on-line UPS that may operate in the following alternative modes: Normal mode ◆ The rectifier/charger derives power from the AC Mains and supplies DC power to the inverter while floating and boosting charge the battery simultaneously. Then, the inverter converts the DC power to AC and supplies to the load.

  • Page 17: Test Procedure

    Turn ON the power switch of the monitoring module, so that the UPS system can communicate normally through the monitoring unit. When hot-swap this monitoring unit, the power switch must be OFF. ◆ Turn ON output breaker. ◆ Turn ON the input and bypass switches of all UPS modules, which locate at the modules’...

  • Page 18: Maintenance Bypass

    ◆ Turn on the Output switch ◆ Trigger the cold start buttons of the modules respectively as the position 5 of the above Drawing： When battery normal, rectifier starts operation, 30s later, inverter starts and operates and battery LED on CAUTION! Wait for approximately 30 seconds before you press the black start key 4.2.4 Maintenance bypass...

  • Page 19: Shut Down Procedure

    The rectifier will operate normally after 30 seconds. If the inverter works normally, the system will be transferred from bypass mode to normal mode. 4.2.5 Shut down procedure CAUTION! This procedure should be followed to completely shut down the UPS and the LOAD.

  • Page 20: The Display

    4.3 The Display 4.3.1 System LCD display Overview of the operating panel of the UPS Introduction CAUTION! The display provides more functions than those described in this manual. 4.3.1.1 Home page 1, show the UPS operating flow chart, and there are the data entrance of input, output, battery.
  • Page 21 1) Click on the bypass icon to enter the bypass data window, click on the back icon return to last window and click on the homepage icon jump to main page. 30kVA 2) Click on the mains icon to enter the mains data window, click on the back icon return to last window and click on the homepage icon jump to main page.
  • Page 22 3) Click on the Load icon to enter the output data window, click on the back icon return to last window and click on the homepage icon jump to main page. 30kVA 4) Click on the battery icon to enter the battery data window, click on the back icon return to last window and click on the homepage icon jump to main page.
  • Page 23 4.3.1.2 Click on Runn. info icon to enter the information page. 30kVA 1) Click on the Run time icon to enter the status data window, can see the breaker status, click on the back icon return to last window and click on the homepage icon jump to main page. 30kVA...
  • Page 24 2) Click on the ENV data icon to enter the status data window, can see the temperature data after connected to temperature sensor , click on the back icon return to last window and click on the homepage icon jump to main page. 30kVA 4.3.1.3 Click on Alarm icon to enter the alarms page.
  • Page 25 1) Click on the active Alarm icon to enter the module data window, can see the alarm data, click on the back icon return to last window and click on the homepage icon jump to main page. 30kVA 2) Click on the history icon to enter the history window, can see the history data, click on the back icon return to last window and click on the homepage icon jump to main page.
  • Page 26 4.3.1.4 Click on setting icon to enter setting page, click on the back icon return to last window and click on the homepage icon jump to main page 30kVA 4.3.1.5 Click on Maintenance icon to enter setting page, click on the back icon return to last window and click on the homepage icon jump to main page 30kVA...

  • Page 27: Ups Module Lcd Display

    4.3.1.6 Click on Function icon to enter setting page, click on the back icon return to last window and click on the homepage icon jump to main page 30kVA 4.3.2 UPS Module LCD display Overview of the operating panel of the UPS 1）LED indicator 2）LCD Display 3）scroll button: enter to next item...
  • Page 28 Version of rectifier software, version of inverter Software version & model software, model CODE Alarm Code(Warming Message) 1) When the UPS is connecting with the Utility or Battery at cold start mode, it shows as drawing below: Cabinet ID Module ID Status 1.
  • Page 29 6. Bat – (Negative) 7. Output Voltage/Frequency 8. Load Capacity 9. Internal temperature and ambient temperature 10. Software version & model 11. Alarm Code If some of above interfaces have battery charging, it will display the charging information at the same time as shown below.

  • Page 30: Monitoring Module Control Panel

    Charging Status Boost Floating 3) Pressing “scroll” button, you may circulate all messages from the first one to the last one then returns back to the first one and vice versa. 4) All alarm codes are present when abnormal behavior(s) occur(s). 4.3.3 Monitoring module control panel Monitoring module control panel is at UPS top.

  • Page 31: Display Messages/Troubleshooting

    Battery indicator Yellow Battery Normal, but discharging and powering the load Flashing Battery End of Discharge pre-warning, Battery abnormal (high Green or low voltage, Absent or Polarity Reversed), charger abnormal Battery and Converter Normal, Battery charging. Bypass indicator Green Load on Bypass power Flashing Bypass not available, out of normal range, Static bypass Green...
  • Page 32 Module Alarm Information Event log UPS Alarm Warning Buzzer Rectifier Fault Beep continuously Fault LED lit Inverter fault(Including Inverter Beep continuously Fault LED lit bridge is shorted) Inverter Thyristor short Beep continuously Fault LED lit Inverter Thyristor broken Beep continuously Fault LED lit Bypass Thyristor short Beep continuously...
  • Page 33 Cabinet Display messages Events: Display message Meaning Initializing The DSP and MCU are in Initializing. Standby The UPS does not provide power to the load Non-Output equipment. Inverter output is turned off and the load connected On Bypass at the inverter output receives power from utility line via STS.
  • Page 34 Latched load transfer to bypass as a result of too many successive transfers within the current hour. Transfer Times-out Automatic reset attempt within the next hour. The load exceeded the power capacity. The UPS has UPS In shutdown Due To Overload.
  • Page 35 The UPS is in battery operation and the battery voltage is Battery under-voltage low. pre-warning Note: Runtime is limited in duration. Mains frequency is out of limit range and results in rectifier 21 Mains freq. abnormal shutdown. Mains Voltage exceeds the upper or lower limit and 22 Mains volt.

  • Page 36: Options

    47 Ext. Smoke Alarm External smoke detector has been activated. 48 battery damaged Battery has been damaged, this warning shall occur. 49 battery over-temperature Battery over-temperature, this warning shall occur. 50 model set wrong Model setting of the UPS is incorrect. 4.5 Options Network Management Card with Environmental Monitoring CAUTION!

  • Page 37: Appendix 1 Specifications

    Function Description Input or Output Utility Failure Battery Low Bypass On Output UPS Fault Inverter On Summary Alarm common Remote Shutdown + Input (5~12V) Appendix 1 Specifications Model 30kVA 50kVA 45kVA 6~30kVA 10~50kVA 15~45kVA UPS Cabinet 6~30kW 10~50kW 15~45kW Capacity UPS Module 6kVA/6kW 10kVA/10kW...

  • Page 38: Appendix 2 Problems And Solution

    Efficiency up to 94% ±96/108/120Vdc (16/18/20pcs ±192/204/216/22 optional); Voltage (16 pcs define, 20 pcs no power 8/240Vdc; battery quantity(optional) derating; 18 pcs output power factor Battery 0.9; 16 pcs output power factor 0.8;) UPS Cabinet 60A Max. 80A Max. Charging UPS Module 12A Max.
  • Page 39 Problem Possible reason Solution The network cable is not fixed Connect the network cable and properly or the telephone line LCD not display telephone cable properly. of the front door is not fixed properly. Take out the cable and insert LCD Blue screen LCD is Interference back properly...

  • Page 40: Appendix 3 Rs232 Communication Port Definition

    Set the UPS working mode to The UPS is set to ECO mode, The UPS only works on Single Module mode, change the or the UPS is under bypass mode maintenance mode to normal maintenance mode. mode. Battery switch is not properly Close the battery switch；...
  • Page 41 Appendix 4 RS485 communication port definition Definition of Male port Connection between RS485 port and UPS RS485 port RS485 port UPS RS485 port Pin 1 Pin 1 485 -“B” Pin 2 Pin 2 485+ “A“ Available function of RS485 ◆ Monitor UPS power status. ◆...
