APCI-7800
4.3

Limit values

Max. altitude: ............................................ 2000 m
Operating temperature: .............................. 0 to 60°C
Storage temperature: ................................. -25 to 70°C
Relative humidity: ..................................... 30% to 99% non condensing
Minimum PC requirements:
PCI BIOS from Version 1.0
Bus speed: ................................................. < 33 MHz
Operating system: ..................................... Windows NT, 98, 2000, XP
Energy requirements:
- Operating voltage of the PC: .................. 5 V ± 5%
- Current consumption (without load): ...... typ. see table ± 10%
+ 5 V from PC
Add to this data the current consumption of the used modules according to
the following table:
1
Module PMTTY or MXTTY (20 mA) is optically isolated as a standard.
14
APCI-7800
425 mA
PMxxx
RS 232
RS 422
RS 485
20 mA
1 PMxxx-G
21 mA 48 mA
5 mA 42 mA
5 mA 54 mA
51 mA -
Technical data
