APCI-7800
6.2

Configuration under Windows XP/2000/98

In the Windows device manager you can set the different interfaces
according to your requirements through double clic.
Start the device manager of your operating system under
Start/(Settings)/Control panel/System
In the "FIFO" register the following settings are possible:
Management of
the transmitter
and receiver
buffer
Data flow
control
In "Setting" you adapt the operating mode to the used interface.
You can select the quartz frequency for example and decide whether the
modem control signals for RS232 are internally connected.

Fig. 6-4: FIFO settings with the Device Manager

Reset the standard settings
PCI bus and
device number
Software
29
