Polycystic Kidneys
S S t t e e p p 1 1
Select the anomaly and turn the manikin face down to expose
the back of the body skin.
S S t t e e p p 2 2
Detach the skin from the lower 2 sets of pegs.
S S t t e e p p 3 3
Insert an anomaly on each side of the manikin as shown.
NOTE/Caution: Do not cover the left side ECG connector
with the left polycystic kidney insert.
S S t t e e p p 4 4
Re-attach the body skin on the pegs.
Note: When the polycystic kidneys are in place, there will be a
slight bulge on each side of the manikin (see arrow).
