Introduction

The Mechanical Vibration Switch is a shock sensitive mechanism for shutdown of engine or electric motor
powered equipment. This switch uses a patented linear adjustment magnetic latch technology to ensure reliable
operation. Pushing the reset button moves the tripping latch into a magnetically held position. A shock/vibration
will move the magnet beyond this holding position, thus freeing the spring loaded tripping latch to transfer the
contacts and shut down the machinery.

General Features

•
Designed to Detect Shock/Vibration in 3 Planes of Motion
•
Fully Adjustable, with linear adjustment technology
•
Includes Magnetic Latching Feature
•
Accommodates normally open (NO) and normally closed (NC) wiring schemes
•
Manual Reset Button
•
IP66 rated enclosure
•
Remote Reset
- EX685A19: 24VDC Remote Reset
- EX685A29: 120VAC Remote Reset
- EX685A39: 240VAC Remote Reset
•
Top cover is secured with socket head cap screws for easy access to wiring terminals
AC and DC input signals and power supply voltages could be hazardous.
- DO NOT connect live wires to screw terminal plugs
- DO NOT insert, remove, or handle screw terminal plugs with live wires connected
- DO NOT make any adjustments to the setpoint with live wires present
- DO NOT open the unit if machine is powered or running
- DO NOT open the unit if the Relays are energized
- DO NOT open the unit if the Reset Coil is energized
- DO NOT make any adjustments if machine is energized and/or power is present
anywhere in the switch.
BEFORE BEGINNING INSTALLATION OF THIS IMI PRODUCT:
✓ Stop the machine.
✓ Disconnect all electrical power to the machine.
✓ Make sure the machine cannot operate during installation by following proper lock out tag out procedures.
✓ Follow all safety warnings of the machine manufacturer.
✓ Read and follow all installation instructions.

WARNING
