Certificate: 70031613
Project: 70153084
This includes equipment supply, description of I/O connections and operating environmental conditions.
1. Pollution degree 2;
2. Installation category II;
3. Altitude 2000m;
4. Electrical supply 24Vdc, 120 Vac, 240 Vac
5. Temperature 5°C to 40°C
Do not exceed the maximum relay ratings as noted below.
6. Warning:
Rated Voltage
AC 125V
AC 250V
AC 480V
DC 8V
DC 14V
DC 30V
DC 125V
DC 250V
Equipment Installation:
This includes instructions for mounting, location requirements, details for special services if any.
HAZ LOC MARKINGS:
The following markings appear:
- Company name
- Model number
- Serial number
- Electrical rating
- Haz loc rating:
- CSA Monogram with C/US indicators
- Ambient temperature range
- Caution re Explosion hazard
WARNING – DO NOT OPEN WHEN ENERGIZED
-
- WARNING – A SEAL SHALL BE INSTALLED WITHIN 50 mm OF THE ENCLOSURE
- WARNING – AFTER DE-ENERGIZING, DELAY X* MINUTES BEFORE OPENING.
CAUTION – USE FASTENERS WITH YIELD STRESS ≥ 450 MPa
-
* Opening time (minute)
Option
DQD 507 Rev. 2012-05-22 Page 4
Resistive Load Inductive Load
15A 10A
15A 10A
3A
15A 15A
15A 10A
6A
0.5A 0.05A
0.25A 0.03A
2
Without remote
Motor, Lamp Load
N.C
4A
3A
2A -
-
-
5A -
-
-
26
With remote reset
Master Contract: 184981
Date Issued: 2017-11-21
N.O
2A
1.5A
-
-
-
-
-
-
