Model Number
EX685A09
Performance
Measurement Range
Frequency Range
Relay 3A Form C 480 VAC
Relay(Contacts)(DPDT) Normally Open / Closed
Control Interface
Reset Function Momentary Pushbutton
Environmental
Temperature Range(Operating)
Hazardous Area Approval
Enclosure Rating
Physical
Size (Width x Height x Depth) 6.38 in x 4.18 in x 6.38 in
Weight
Sensing Element
Housing Material
Electrical Connector
Screw Terminal Wire Size
Cable Input
Sensing Geometry
[1]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
VIBRATION SWITCH
EN GLISH SI
0 to 7 g pk 0 to 68.7 m/s² pk
0 to 6,000 cpm 0 to 100 Hz
3A Form C 480 VAC
Normally Open / Closed
Momentary Pushbutton
Switch Switch
-4 to 140 °F -20 to 60 °C
See Manual See Manual
IP66 IP66
162.1 mm x 106.3 mm x 162.1
mm
6.1 lb 2.7 kg
Magnet Magnet
Aluminum Alloy Aluminum Alloy
Screw Terminals Screw Terminals
24-14 AWG 0.2 - 2.5 mm²
3/4-14 NPT 3/4-14 NPT
Inertial Element Inertial Element
OPTION AL VERSION S
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
N OTES:
[1]See PCB Declaration of Conformance PS145 for details.
Entered: ND Engineer: LAB Sales: JL
Date: 12/18/2023 Date: 12/18/2023 Date: 12/18/2023 Date: 12/18/2023 66340
3425 Walden Avenue, Depew, NY 14043
Revision: NR
ECN #: 54129
Approved: NJF Spec Number:
