Introduction

The Mechanical Vibration Switch is a shock sensitive mechanism for shutdown of engine or electric motor
powered equipment. This switch uses a patent pending linear adjustment magnetic latch technology to ensure
reliable operation. Pushing the reset button moves the tripping latch into a magnetically held position. A
shock/vibration will move the magnet beyond this holding position, thus freeing the spring loaded tripping latch to
transfer the contacts and shut down the machinery.

General Features


Designed to Detect Shock/Vibration in 3 Planes of Motion

Fully Adjustable, with patent pending linear adjustment technology

Includes Magnetic Latching Feature

Accommodates normally open (NO) and normally closed (NC) wiring schemes

Manual Reset Button

IP66 rated enclosure

Remote Reset
685A19: 24VDC Remote Reset
-
685A29: 120VAC Remote Reset
-
- 685A39: 240VAC Remote Reset

Top cover is secured with socket head cap screws for easy access to wiring terminals
AC and DC input signals and power supply voltages could be hazardous.
- DO NOT connect live wires to screw terminal plugs
- DO NOT insert, remove, or handle screw terminal plugs with live wires connected
- DO NOT make any adjustments to the setpoint with live wires present
- DO NOT open the unit if machine is powered or running
- DO NOT open the unit if the Relays are energized
- DO NOT open the unit if the Reset Coil is energized
- DO NOT make any adjustments if machine is energized and/or power is present
anywhere in the switch.
BEFORE BEGINNING INSTALLATION OF THIS IMI PRODUCT:
 Stop the machine.
 Disconnect all electrical power to the machine.
 Make sure the machine cannot operate during installation by following proper lock out tag out procedures.
 Follow all safety warnings of the machine manufacturer.
 Read and follow all installation instructions.
