■Pin Assignment
4 5 6 7 8 9 10
+
b B A
RTD
INPUT
AUX. POWER
■Operation Key
Operation keys: Left (Escape) /
In page settings, the screen will return to the measurement page without pressing any keys for 2 minutes, or press
(1)In any page, press for into
Enter/Function
key (2)In function index page, press for setting
(1)Press and hold for 2 seconds to go back the previous
Shift key
page
Up key (1)Press to go back to previous function index
Down key (1)Press to go to next function index
■Parameters
Parameter
PVDP Decimal point setting of PV
pVdp
PVZRO PV fine adjustment of zero
pVzro
pVspn PVSPN PV fine adjustment of span
PSclr PSCLR Clear fine adjustment of zero/span
lOcut LOCUT Low cut setting
avg AVG Average setting for reading
MVAVG Moving average setting for reading
mVavg
DFILT Digital filter setting for reading
DFilt
PCODE Pass code setting
Pcode
MAX Maximum value
max
MIN Minimum value
min
M.RST Maximum and Minimum value reset
m.rst
TYPE Model name and version
type
init INIT Meter initialize
unit UNIT Unit setting
2/3
Terminal blocks:
10A/300Vac, M2.5
2
1.3~2.0mm (16~22AWG)
－
AC 85~264V
ADH
DC 100~300V
DC
UP key / Down key /
Function Index
Explanation
Enter(Function) key
(3)Setting Confirmed and save
(2)In page settings, press and hold for 2 seconds to go back the
previous page (save
(3)In number setting, press for shift the setting position
(2)In parameters setting, press for item select
(3)In number setting, press for increase number
(2)In parameter setting, press for item select
(3)In number setting, press for decrease number
0、0.0
1. ℃ :-199.9~800.0 2. ℉ :-326.2~1472.0
1. ℃ :-199.9~800.0 2. ℉ :-326.2~1472.0
NONE、PVZRO、PVSPN、BOTH
-1999~9999
1~99 time
1~10 time
0(None)/1~99 time
0000~9999
Read only
Read only
YES / NO
TR
7170
℃ / ℉
CS3S-TR
and hold for 2 seconds.
Parameters Setting
Range
2023-03-10
Rev 1.2
