Appendix B Specifications

Item
Standards
Transmission Medium
Frame Forward Rate
LEDs
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Content
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.1p
IEEE 802.3af, IEEE 802.3at, IEEE 802.3z
10Base-T: 2-pair UTP/STP of Cat. 3 or above (maximum 100 m)
100Base-TX: 2-pair UTP/STP of Cat. 5 or above (maximum 100 m)
1000Base-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
1000BASE-SX: 62.5 μm MMF (Minimum range: 2 m to 275 m) or 50 μm MMF
(Minimum range: 2 m to 550 m)
1000BASE-LX: 62.5 μm/50 μm MMF (Minimum range: 2 m to 550 m) or 10 μm
SMF (Minimum range: 2 m to 5000 m)
1000BASE-LX10: Type B1.1, B1.3 SMF (2 fiber) (Minimum range: 0.5 m to 10000 m)
1000BASE-BX10: Type B1.1, B1.3 SMF (1 fiber) (Minimum range: 0.5 m to 10000 m)
10Base-T: 14881 pps/Port
100Base-X: 148810 pps/Port
1000Base-T: 1488095 pps/Port
1000BASE-X: 1488095 pps/Port
PWR, Link/Act, PoE Status, PoE MAX, FAN
-10°C to 50°C (14°F to 122°F)
-40°C to 70°C (-40°F to 158°F)
10% to 90%RH Non-condensing
5% to 90%RH Non-condensing
Unmanaged Rackmountable Switch
