- Page 1 Business Networking Solution Installation Guide Unmanaged/Easy Smart Rackmountable Switches...
- Page 3 Network Administrator Conventions • When using this guide, notice that features available in TP-Link | Omada series products may vary by model and software version. Availability of TP-Link | Omada series products may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual experience.
-
Page 4: Table Of Contents
Contents Chapter 1 Introduction ––––––––––––––––––––––– 1 Product Overview ............. 1 Appearance ................ 1 Chapter 2 Installation –––––––––––––––––––––––– 6 Package Contents ............6 Safety Precautions ............6 Installation Tools ............... 8 Product Installation ............8 Chapter 3 Connection –––––––––––––––––––––––– 10 Ethernet Port ..............10 SFP Port ................ -
Page 5: Chapter 1 Introduction
Unmanaged/Easy Smart Rackmountable Switches Chapter 1 Introduction Product Overview The Unmanaged/Easy Smart Switch provides you with a low-cost, easy-to-use, high-performance, seamless, and standard upgrade to improve your network to 100 Mbps or 1000 Mbps. DS1018GMP is also a Power Sourcing Equipment (PSE*). The 10/100/1000 Mbps RJ45 ports 1–16 on DS1018GMP support the Power over Ethernet (PoE*) function, which can automatically detect and supply power to those powered devices (PDs*) complying with IEEE 802.3af and IEEE 802.3at. - Page 6 Unmanaged/Easy Smart Rackmountable Switches The front panel of DS1024G is shown as the following figure. Figure 1-3 Front Panel of DS1024G LEDs 10/100/1000 Mbps RJ45 Port The front panel of DS1024GE is shown as the following figure. Figure 1-4 Front Panel of DS1024GE Reset LEDs 10/100/1000 Mbps...
- Page 7 Unmanaged/Easy Smart Rackmountable Switches Indication On: The switch is powered on. Power Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal/Loop Prevention function is enabled. Note: PWR for DS1018GMP; Power for other models. On: Running at 1000 Mbps.
- Page 8 Unmanaged/Easy Smart Rackmountable Switches Switch Explanation Switch Indication Priority Off: All the ports transmit data with the same priority. (For DS1018GMP) On: The specific ports transmit data with a higher priority than other ports. Off: Ports can transmit data with each other. Isolation (For DS1016G/ On: Specific ports cannot transmit data with other downlink ports.
- Page 9 PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed information, refer to the Lightning Protection Guide from the Related Documents of our website: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide. Power Socket Plug the female connector of the power cord directly into the power socket and plug the male connector into an AC outlet.
-
Page 10: Chapter 2 Installation
Unmanaged/Easy Smart Rackmountable Switches Chapter 2 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, contact your distributor. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted. - Page 11 Unmanaged/Easy Smart Rackmountable Switches Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion. High temperatures may accelerate aging of the insulation materials, significantly shortening the service life of the device.
-
Page 12: Installation Tools
Note: For detailed lightning protection measures, refer to the Lightning Protection Guide from the Related Documents of our website: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide. Installation Site When installing the device on a rack or a flat workbench, attach much importance to the following items: The rack or workbench is flat, stable, and sturdy enough to support the weight of 5.5 kg at least. - Page 13 Unmanaged/Easy Smart Rackmountable Switches Figure 2-1 Desktop Installation Feet Bottom of the Device Notch Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: 1. Check the efficiency of the grounding system and the stability of the rack. 2.
-
Page 14: Chapter 3 Connection
Unmanaged/Easy Smart Rackmountable Switches Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP Port The following figure demonstrates the connection of SFP port to an SFP module. Figure 3-2 Inserting the SFP Module SFP Slot... -
Page 15: Power On
Unmanaged/Easy Smart Rackmountable Switches The power socket, device and rack are well grounded. ■ The device is correctly connected to other network devices. ■ Power On Plug the negative connector of the provided power cord into the power socket of the device and plug the positive connector into a power outlet as the following figure shows. - Page 16 User Guide. You can find the latest version of this guide on the official website: https://www.tp-link.com/download-center.html. Using the Configuration Utility You can find the configuration utility from the official website: https://www.tp-link.com/download- center.html. For detailed information about using the configuration utility, refer to the Easy Smart Configuration Utility User Guide.
-
Page 17: Appendix A Troubleshooting
Unmanaged/Easy Smart Rackmountable Switches Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the Switch? With the switch powered on, press the Reset button for at least 5 seconds to reset the system. The system will be reset to the factory default settings, and the default login user name and password are both admin. -
Page 18: Appendix B Specifications
Unmanaged/Easy Smart Rackmountable Switches Appendix B Specifications Item Content IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.1p Standards IEEE 802.1q (for DS1016GE/DS1024GE) IEEE 802.3af, IEEE 802.3at, IEEE 802.3z( only for DS1018GMP) 10Base-T: 2-pair UTP/STP of Cat. 3 or above (maximum 100 m) 100Base-TX: 2-pair UTP/STP of Cat. - Page 19 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/...
- Page 20 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2023 TP-Link 7106510715 REV1.0.0...
