- Page 1 Business Networking Solution Installation Guide Unmanaged Rackmountable Switch...
- Page 2 Network Administrator Conventions • When using this guide, notice that features available in TP-Link | Omada series products may vary by model and software version. Availability of TP-Link | Omada series products may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual experience.
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction ––––––––––––––––––––––– 1 Product Overview ............. 1 Appearance ................ 1 Chapter 2 Installation –––––––––––––––––––––––– 4 Package Contents ............4 Safety Precautions ............4 Installation Tools ............... 6 Product Installation ............6 Chapter 3 Connection –––––––––––––––––––––––– 8 Ethernet Port ..............8 SFP Port ................ -
Page 4: Chapter 1 Introduction
Unmanaged Rackmountable Switch Chapter 1 Introduction Product Overview The Unmanaged Switch provides you with a low-cost, easy-to-use, high-performance, seamless, and standard upgrade to improve your network to 100 Mbps or 1000 Mbps. DS1018GMP is also a Power Sourcing Equipment (PSE*). The 10/100/1000 Mbps RJ45 ports 1–16 on DS1018GMP support the Power over Ethernet (PoE*) function, which can automatically detect and supply power to those powered devices (PDs*) complying with IEEE 802.3af and IEEE 802.3at. - Page 5 Unmanaged Rackmountable Switch Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal/Loop Prevention function is enabled. Green On: Running at 1000 Mbps but no activity. Green Flashing: Running at 1000 Mbps and is transmitting or receiving data. Yellow on: Running at 100/10 Mbps but no activity.
- Page 6 PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed information, refer to the Lightning Protection Guide from the Related Documents of our website: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide. Power Socket Plug the female connector of the power cord directly into the power socket and plug the male connector into an AC outlet.
-
Page 7: Chapter 2 Installation
Unmanaged Rackmountable Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, contact your distributor. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted. - Page 8 Unmanaged Rackmountable Switch Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion. High temperatures may accelerate aging of the insulation materials, significantly shortening the service life of the device.
-
Page 9: Installation Tools
Note: For detailed lightning protection measures, refer to the Lightning Protection Guide from the Related Documents of our website: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide. Installation Site When installing the device on a rack or a flat workbench, attach much importance to the following items: The rack or workbench is flat, stable, and sturdy enough to support the weight of 5.5 kg at least. - Page 10 Unmanaged Rackmountable Switch Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: 1. Check the efficiency of the grounding system and the stability of the rack. 2. Secure the supplied rack-mounting brackets to each side of the device with supplied screws, as illustrated in the following figure.
-
Page 11: Chapter 3 Connection
Unmanaged Rackmountable Switch Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP Port The following figure demonstrates the connection of SFP port to an SFP module. Figure 3-2 Inserting the SFP Module SFP Slot... -
Page 12: Power On
Unmanaged Rackmountable Switch The power socket, device and rack are well grounded. ■ The device is correctly connected to other network devices. ■ Power On Plug the negative connector of the provided power cord into the power socket of the device and plug the positive connector into a power outlet as the following figure shows. -
Page 13: Appendix A Troubleshooting
Unmanaged Rackmountable Switch Appendix A Troubleshooting Q1. Why is the Power/PWR LED not lit? By default, the Power/PWR LED should be lit when the power system is working normally. If the Power/PWR LED is not lit, please try the following: Make sure that the power cable is connected properly, and the power contact is normal. -
Page 14: Appendix B Specifications
Unmanaged Rackmountable Switch Appendix B Specifications Item Content IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.1p Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3z 10Base-T: 2-pair UTP/STP of Cat. 3 or above (maximum 100 m) 100Base-TX: 2-pair UTP/STP of Cat. 5 or above (maximum 100 m) 1000Base-T: 4-pair UTP/STP of Cat. - Page 15 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/...
- Page 16 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2023 TP-Link 7106510544 REV1.0.0...
