Chapter 1: Getting Started

Before you begin...

It is recommended that the following items be available to make this short step-by-step
introduction to the CLICK PLUS PLC go smoothly.
CLICK PLUS PLC unit
CLICK 24VDC Power Supply Other 24VDC Power Supply
C0-00AC or C0-01AC Example: PSP24-60S
or
CLICK
PC Running
Based on your CLICK PLUS PLC,
Programming Software
Windows
One of the cables shown below:
C0-PGMSW
Ethernet Cat5 Cable
USB A to USB micro B
USB or Free download @
Programming
http://support.automationdirect.com/
Not available from ADC.
Cable Assembly
products/clickplcs.html
USB-CBL-AMICB6
Screwdriver
TW-SD-MSL-2
AC Power Cord
PC Programming Cable
D2-DSCBL
Wire Strippers
Hookup Wire
DN-WS
PC requires RS-232 port.
Not available from ADC.
1-4
