Chapter 1: Getting Started

Step 7: Establish PC to PLC Communications

Next, connect a personal computer (PC) to the CLICK PLUS PLC unit. You can use any of
the following communication ports on the CLICK PLUS PLC unit for programming,
depending on model.
NOTE: Connection via wireless LAN requires provisioning the CLICK PLUS PLC onto your wireless LAN. This initial
setup can be performed through the CLICK Provisioning mobile app over Bluetooth, as described on page 1-21. It
can also be done through the USB connection or wired LAN connection with the CLICK programming software.
1-18
CLICK PLUS PLC Hardware User Manual, 1st Edition, Rev. K – C2-USER-M
Wireless LAN
(Antenna purchased
separately)
Micro USB Port
Port 1 (Ethernet)
Port 2 (RS-232)
