CONNECTORS LIST
J10 STEP MOTOR CONNECTOR
No. SIGNAL
1 +12VDC Motor Neutral Wire
2 +12VDC Motor Neutral Wire
3 Phase 1
4 Phase 2
5 Phase 3
6 Phase 4
7 +5VDC
8 GND
9 Paper Signal
10 Power on LED
11 n.c.
12 n.c.
13 +5 VDC
14 GND
15 Notch Signal
16 Power on LED
This connector is EPSON M260-C-compatible, but it may also be used with other types of step motors.
The photocell signals are on the connector.
J2 PRINTER CONNECTOR
No. FUNCTION
1 Trigger magnet -
2 Trigger magnet +
3 Reset detector
4 GND
5 GND
6 Solenoid A
7 Solenoid B
8 Solenoid C
9 +12 VDC
10 +12 VDC
11 +12 VDC
12 Solenoid D
13 Solenoid E
14 Solenoid F
15 Solenoid G
16 +12 VDC Motor
17 Timing detect
18 Timing detect
19 Motor
20 n.c.
(see J8)
(see J7)
