CONNECTORS LIST

J1 CUTTER CONNECTOR
No. SIGNAL
1 Cutter position sensors
2 Cutter position sensors
3 GND
4 Cutter Motor 1 Control
5 Cutter Motor 2 Control
J4 POWER SUPPLY CONNECTOR
No. SIGNAL
1 +12 – 14 VDC
2 GND
J5 RS232 SERIAL CONNECTOR
No. SIGNAL
1
2 TX
3 RX
4
5 GND
6 DSR
7
8 RTS
9
FUNCTION
RS-232 Data output
RS-232 Data input
GND
Printer ON Indicator (+12 V active)
Request to send
