DEMO MANUAL DC1922A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 2 C2, C4
3 1 C3
4 2 C5,C6
5 1 C7
6 1 C9
7 1 C10
8 1 L1
9 1 Q1
10 4 R1, R4, R5, R6
11 1 R2
12 1 R3
13 1 U1
Additional Demo Board Circuit Components
1 0 C8
2 0 C11
3 0 D1
4 0 R7, R8, R9
Hardware: For Demo Board Only
1 5 E1, E2, E3, E4, E5
2 1 J1
3 4 JP1, JP2, JP3, JP4
4 4 XJP1, XJP2, XJP3, XJP4
5 4 (STAND-OFFS)
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP CER 22µF, 25V, X5R, 20%,1210
CAP CER 1.0µF, 25V, X5R, 20%, 0603
CAP CER 22µF, 10V, X5R, 20%, 1210
CAP CER 22000pF, 50V, X7R, 10%, 0603
CAP CER 33pF, 50V, 5%, NP0 0603
CAP CER 2.2µF, 10V, X7R, 20%, 0603
CAP CER 10pF, 50V, NP0, ±0.25pF 0603
INDUCTOR, 10µH
N-CHANNEL MOSFET, 20V, SOT23
RES,CHIP, 2.0M, 1/16W, 1%, 0402
RES, CHIP, 619k, 1/16W,1%, 0402
RES, CHIP, 2.21k, 1/16W, 1%, 0402
15V, 200mA SYNCHRONOUS BUCK - BOOST DC / DC CONVERTER
WITH 1.3µA QUIESCENT CURRENT
CAP TANT 68µF, 20V, 10%, SMD 7343 (OPT)
CAP CER 6.3V, 0603 (OPT)
DIODE SCHOTTKY (OPT)
RES 1/10W, 1%, 0402 SMD (OPT)
TESTPOINT, TURRET 0.094"
HEADER, 2 × 6, 12-PIN, SMT HORIZONTAL SOCKET W/KEY, 0.100" SAMTEC, SMH-106-02-L-D-05
JMP, 0.079 SINGLE ROW HEADER, 3 PIN
SHUNT, .079" CENTER
STAND-OFF, NYLON 0.625" Tall
MANUFACTURER/PART NUMBER
TDK, C3225X5R1E226M
TDK, C1608X5R1E105M
TDK, C3225X5R1A226M
TDK, C1608X7R1H223K
TDK, C1608C0G1H330J
TDK, C1608X7R1A225M
TDK, C1608C0G1H100C
COILCRAFT, EPL3015-103
DIODES/ZETEX, ZXMN2F30FHTA
VISHAY, CRCW04022M00FKED
VISHAY, CRCW0402619KFKED
VISHAY, CRCW04022K21FKED
LINEAR TECHNOLOGY, LTC3129EUD
OPT
OPT
OPT
OPT
MILLMAX 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
KEYSTONE, 8834(SNAP ON)
