- Page 2 USER MANUAL 1. BEFORE YOU BEGIN Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling.
- Page 3 3. SET UP 1. Before installation, please be sure to distinguish clearly the ac power input port of lamps and lanterns and the controller signal input port, avoid the wrong line and burn the lamps and lanterns. S i g n a l I n p u t P o w e r I n p u t S i g n a l O u p u t P o w e r...
- Page 4 5. With a fixed base connection between various pieces of lamps and lanterns. 6. Each column of the first piece of lamps and lanterns is connected to external power and signal lines. The same column of lamps and lanterns, connect the power cord after a signal lines and before a signal wire and power cable.
- Page 5 SD controller splicing diagram Attention: 1.Plug in or pull out plug signal and SD card in power up situation are not allowed. 2， Please do not turn on light and SD controller at the same time, it will cause the current to impact SD controller easily.
- Page 6 Connection base:...
