I n s t a l l a t i o n & S e r v i c i n g
Natural Gas Boilers
Boiler
G.C No
iR 12
47-310-30
iR 15
47-310-32
iR 18
47-310-34
iR 24
47-310-36
iR 32
47-310-38
iR 40
47-310-40
CE PIN 0063CQ3634
These instructions are to be retained by the user.
Instructions
Propane Gas Boilers
Boiler
G.C No
iR 12 LPG
47-310-31
iR 15 LPG
47-310-33
iR 18 LPG
47-310-35
iR 24 LPG
47-310-37
iR 32 LPG
47-310-39
iR 40 LPG
47-310-41
iR 12
iR 15
iR 18
iR 24
iR 32
iR 40
Open Vent System
Advertisement
Table of Contents
Related Manuals for Atag iR 12
Summary of Contents for Atag iR 12
- Page 1 40 Open Vent System Natural Gas Boilers Propane Gas Boilers Boiler G.C No Boiler G.C No iR 12 47-310-30 iR 12 LPG 47-310-31 iR 15 47-310-32 iR 15 LPG 47-310-33 iR 18 47-310-34 iR 18 LPG 47-310-35 iR 24...
- Page 2 Press 6 seconds for Information Reset button reset DHW button +/-function (ancillary function: Scroll and +/-function) Commissioning function (Press both + buttons for 6 seconds) See chapter 12 for more information about button functions and read-out. Installation & Servicing instructions ATAG iR-Range...
-
Page 3: Table Of Contents
System water additives .....................47 Annex B Declaration of conformity ....................48 Annex C Short parts list ........................49 Work on the installation should only be carried out by qualified personnel with calibrated equipment and appropriate tools. Installation & Servicing instructions ATAG iR-Range... -
Page 4: Introduction
These instructions are intended for the use of Gas Safe registed installers in connection with the installation and putting into operation of ATAG boilers. It is advisable to read these instructions thoroughly, well in advance of installation. Separate instructions for use are supplied with the boiler for users of ATAG central heating boilers. -
Page 5: Rules & Regulations (Symbols)
Installation Manual. Manufacturers instructions must not be taken, in any way, as overriding statutory obligations. The ATAG iR boiler is a central heating boiler for "open" expansion tank systems (open vent) only. The boiler must be connected according to these instructions and all installation norms in respect of the part of the boiler to be connected. - Page 6 Transport and place the boiler in its packaging in this position. Do not to step on or stand on the package. An assembly or dismantling must be carried out. Pay extra attention in connection with a particular operation. Useful tip or advice Installation & Servicing instructions ATAG iR-Range...
-
Page 7: Technical Specifications
LPG Input CH Net 10.8 13.5 16.2 21.6 28.8 36.0 Output (80/60°C) 10.7 13.3 15.9 21.2 28.4 35.4 Output (50/30°C) 11.8 14.7 17.5 23.2 31.2 38.8 Weight boiler + jig (empty) Installation & Servicing instructions ATAG iR-Range... -
Page 8: Dimensions
Dimensions ATAG iR-Series Regular iR 12 iR 15 iR 18 iR 24 iR 32 iR 40 Flue gas / Air intake 60/100 Gas connection CH Flow connection CH Return connection Condensate drain connection 21.5 Installation & Servicing instructions ATAG iR-Range... -
Page 9: Delivery Package
External controls. Boiler description The ATAG iR is a room sealed, condensing and modulating CH boiler for "open" expansion tank systems (open vent) only. The boiler is equipped with a compact stainless steel heat exchanger with smooth pipes. It is a well thought- out principle using sustainable materials. -
Page 10: Boiler Photo Components List
Boiler data plate Flow switch Air supply damper Siphon Gas pipe 13 Isolation valve flow CH Gas valve Flow pipe CH Automatic de-aerator Isolation valve gas Return pipe CH Control unit Isolation valve return CH Condensation pipe Control panel Installation & Servicing instructions ATAG iR-Range... -
Page 11: Mounting Boiler Frame
400 mm. Remember to connect this earth cable when placing back the boiler front panel and take care the wire does not get stuck between front panel and boiler. Bayonet catch Service space Service space Service dimensions (in mm) Figure 8.a See chapter 9.8 for further procedure to fit the boiler onto the boiler frame. Installation & Servicing instructions ATAG iR-Range... -
Page 12: Wall Frame
The boiler frame allows pipe work to be installed behind the boiler. The pipe work must be installed at least 10mm inside the front of the frame. ATAG i-Serie template and boiler frame Figure 8.1.a Installation & Servicing instructions ATAG iR-Range... -
Page 13: Connecting Boiler
Connect the central heating system according to the current regulations. Open vent heating system 450 mm Recommended relationship Min. height between pump, cold feet and vent. cylinder 1000 mm Min. Heating circuit Pump Boiler 150 mm Max. Scheme open vent system Figure 9.1.a Installation & Servicing instructions ATAG iR-Range... -
Page 14: Water Quality
The warranty becomes invalid, if the installation is not being flushed and/or the quality of the filling water does not meet the specifications recommended by ATAG Heating Technology Ltd. Always contact ATAG Heating Technology Ltd in advance, if things are not clear or you wish to discuss any deviations. Without approval, the warranty becomes invalid. -
Page 15: Heating Systems With Plastic Pipes
No recourse can be made to the terms of the warranty in the event of failure to observe the regulations pertaining to plastic underfloor heating pipes. Installation & Servicing instructions ATAG iR-Range... -
Page 16: Gas Connection In General
ATAG supplies boilers suitable for natural gas only and boilers for LPG only. Verify the identification plate on the boiler if the boiler is suitable for the gas kind on site. The boilers cannot be converted to another kind of gas. - Page 17 In case of a discharge the gasses will go outside. If fitting the regulator outside the regulator should be protected against influences of the weather. The (de-) aeration must be positioned downwards (see figure 9.5.3.a). ATAG advices to install measure points on all gas line parts to have the possibility to check for pressure loss. example propane installation figure 9.4.3.a Pre-pressure must be adjusted to 30 mbar by means of the house pressure regulator. The maximum permitted closing pressure may be 5 mbar higher than the maximum pre-pressure.
-
Page 18: Condensation Drain Pipe
(b) an internal kitchen or bathroom waste pipe, washing machine waste pipe etc. Figure 9.5.3 shows a typical connection method. A suitable permanent connection to the foul waste pipe should be used and the manufacturer’s detailed installation instructions for the pump should be followed. Installation & Servicing instructions ATAG iR-Range... - Page 19 45° Minimum internal diameter 19mm (fall at least 45mm per meter) 7 Pipe size transition Minimum internal diameter 30mm Water/weather proof insulation Drain requirements Figure 9.5.2 (b) Drain requirements Figure 9.5.3 Installation & Servicing instructions ATAG iR-Range...
- Page 20 Draining of the condensation water to the external rain guttering is not permitted in view of the danger of freezing. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iR-Range...
- Page 21 Minimum internal diameter 19mm (fall at least 45mm per meter) 8 Pipe size transition point 9 Pipe size transition point Minimum internal diameter 30mm 10 Minimum internal diameter 30mm 10 Water/weather proof insulation 11 Water/weather proof insulation Drain requirements Figure 9.5.7 Drain requirements Figure 9.5.6 Installation & Servicing instructions ATAG iR-Range...
-
Page 22: Flue Gas Exhaust System
- Air supply pipe; - Roof or wall terminal. The flue gas exhaust system and air supply system must comply with: The flue gas outlet and air supply installation must comply with the current regulation requirements. IG UP 10 and BS 715. The ATAG iR boiler as described in this manual is NOT suitable for a combined flue system. The appliance concentric connection diameter is 60/100 mm, to which the flue gas outlet and air supply system can be fitted, with or without elbow pieces. The maximum permissible pipe length is set out in Table 9.6.2.a. For further information about the available components of the flue gas and air supply system we recommend you consult the Flue system literature. Combinations with other brands or systems are, without written permission from ATAG Heating, not permitted. -
Page 23: Flue Terminal Locations
Figure 9.6.1.a Maximum straight length: 13m: iC 24/28 iR 12/15/18/24 iS 12/15/18/24 6m: iC 36/40 iR 32/40 iS 32/40 3° 89mm 141mm 194mm 246mm 299mm 351mm 403mm 456mm 508mm 560mm 612mm 664mm 716mm Figure 9.6.1.b Installation & Servicing instructions ATAG iR-Range... - Page 24 In certain weather conditions the terminal will emit a plume of steam. If possible avoid positioning the terminal where this may cause a nuisance, i.e. positions A, D, G, H, J or M. 7. The flue terminal must be exposed to the external air and the position must allow the free passage of air across it at all times. 8. A terminal must not be sited below 2m where people have access to, such as public footpaths, access routes, patios etc. However, If the terminal is fitted less than 2m above a surface where there is no public access, the terminal must be protected by a terminal guard. Installation & Servicing instructions ATAG iR-Range...
- Page 25 BS 5440: Part 1 recommends that care is taken when siting terminals in relation to boundaries. Notes: See also Notes on previous page. 2. Plume kits running horizontally must have a 10° fall back to the boiler for proper disposal of condensate. 3. For details on specific lengths see relevant chapter Dimensioning of the flue gas and air intake duct. A terminal must not be sited under a car port roof. Installation & Servicing instructions ATAG iR-Range...
-
Page 26: Dimensioning Of The Flue Gas And Air Intake Duct
Flue dimensions Rear Flue B (mm) Telescopic flue (FA100100) Side Flue B + C (mm) Telescopic flue (FA100100) Rear Flue L = wall thickness (B) + 150mm Side Flue L = wall thickness (B) + distance between boiler and wall (C) + 150mm If the length L is more than 580mm rear flue or 585mm side flue, then a Horizontal flue fixed length 1000mm (60/100mm) with lock function elbow (FA100250) will need to be used instead, up to 810mm. Figure 9.6.2.a Installation & Servicing instructions ATAG iR-Range... - Page 27 6. If the inside sealing collar (white) is being used to make good the inside wall, then it will need to be fitted before assembling the flue. 7. Pull the flue assembly towards the bend, locating the inner duct into the seal joint on the bend and secure the flue assembly to the bend by pushing fully home. 8. Make good the outside wall by fitting the outside sealing collar (grey) onto the location provided immediately behind the flue terminal grille. Make good the inside wall using the inside sealing collar (white) if required. When mounting the flue gas system, pay attention to the flow direction (See Flue figure 9.6.2.b). It is not permitted to mount a system upside down and will lead to complaints. Use a soap solvent or special grease (supplied in the accessory bag with the boiler) to simplify the fitting. Flow direction Figure 9.6.2.b Installation & Servicing instructions ATAG iR-Range...
-
Page 28: Fitting The Boiler Onto The Boiler Frame
1. Press all connection underneath the boiler upwards 2. Put on each valve and the elbow fitting a fibre washer (supplied) ± 50mm Figure 9.7.b 3 and 4. Take the boiler and hang it from approx. 50mm higher than the boiler frame vertical downwards on the boiler frame so the fittings will be axial approached. Installation & Servicing instructions ATAG iR-Range... - Page 29 (click!). Press the sealing ring (8) around the siphon cup and press/turn it in the bottom plate of the boiler. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iR-Range...
-
Page 30: Electrical Connection
- No changes may be made to the wiring of the appliance; - All connections should be designed in accordance with the enclosed regulations; - Should it be necessary to change it, the mains power supply cable may only be replaced with an ATAG mains power supply cable. -
Page 31: Electrical Diagram
10.1 Electrical diagram Figure 10.1.a Installation & Servicing instructions ATAG iR-Range... -
Page 32: Filling System
5 minutes if there is still a demand from the heating. 1.218 2.013 1.170 1.878 1.125 1.753 The ATAG iR is equipped with boiler sensors of 10kOhm. The resistance 1.081 1.638 value and corresponding temperature are shown in the accompanying 1.040 1.531 1.000 1.433... -
Page 33: Controls And Explanation Of The Functions
In other cases the Reset button does not function and will not respond to operation. reset See chapter 17 for a brief overview of codes Ancillary functions: °C Both + buttons = Commissioning-mode for checking the CO CH + button = OK (confirm) (OK) DHW Button: Scroll function (‘scrolling’ through parameters) CH – button = ESC function reset (ESC) (back to standard display) Installation & Servicing instructions ATAG iR-Range... -
Page 34: Commissioning The Boiler
(software version part 1 and software version part 2) The code 105 appears on the display; The 7 minute de-aeration cycle starts; This will take approx. 7 minutes and will be followed by the default display (OK). The iR boilers are supplied with a flow switch. If the external pump starts, the flow switch is made, the burner is set free, if the flow switch not made the boiler will not fire. Installation & Servicing instructions ATAG iR-Range... - Page 35 By pressing both - buttons at the same time for 8 seconds the pump can be switched on continuously. If the pump is set to continuously this is displayed by Boiler frost protection If the (T1) flow sensor registers a temperature of 5°C or below in the boiler, the boiler will fire up. The boiler keeps on firing until the temperature reaches 10°C (measured on the flow sensor) and the boiler switches off again. symbol will flash. In this mode the Installation & Servicing instructions ATAG iR-Range...
-
Page 36: Settings
Boiler type. Do not change! 1 = Natural gas fired boiler, 2 = Boiler with flue non-return valve, 3 = Propane gas fired boiler Service-parameter. Do not change! * Depending of connected type of boiler control Installation & Servicing instructions ATAG iR-Range... -
Page 37: Isolating The Boiler
Switching on with the + button takes place in reverse order. reset ATAG recommends to leave the electrical power supply on, so that the circulation pump is activated automatically once every 24 hours in order to prevent jamming. If there is danger of frost it is advisable in this case to drain the boiler and/or installation. (See following chapter) Installation &... -
Page 38: Commissioning
Always check all gas carrying parts for leaks (with a leak detection spray) after (maintenance) work to the boiler. Close the relevant commissioning valves during the maintenance activities. See figure 15.a. Draining the boiler The heating installation must be provided with a fill and drain valve. Use this feature also for draining the boiler. CH FLOW CH RETURN OPEN CLOSED Figure 15.a Installation & Servicing instructions ATAG iR-Range... -
Page 39: Checking The Co
= 9.0% (-0.4%, +0.6%) 10.3% (+/- 0.6%) - If required, you may turn the setting screw to set the correct CO percentage. (refer to Figure 15.1.b). Adjustment screw CO Figure 15.1.b Installation & Servicing instructions ATAG iR-Range... - Page 40 Propane - CO percentage at low load between 8.7% and 9.6% 9.5% and 10.5% Contact ATAG when the measured values are outside this range. End of measuring: - Press the ESC button ( button). The device switches off. The display shows for 2 seconds code 180 or 181.
-
Page 41: Routine Servicing
Grease the O-ring again with acid-free O-ring grease to simplify the reassembly. Reassembly takes place in reverse order. - fill the siphon with 150 ml of water. If a leakage has occurred to the siphon, replace the entire siphon. Figure 16.b Figure 16.b Installation & Servicing instructions ATAG iR-Range... - Page 42 Turn the left (6) and right (7) clamp bars a quarter turn with the hex key and pull these out in a forward motion. Mind the direction of rotation (red control cams); Now lift the complete fan unit (5) with the upper tray of the heat exchanger and remove it in a forward motion; Installation & Servicing instructions ATAG iR-Range...
- Page 43 To clean the fan, it has to be removed from the upper tray and the venturi. Clean the impeller with a soft brush and a vacuum cleaner. Replace the gasket and take care that the new gasket is installed properly when reassembling the fan parts. Reassembly takes place in reverse order. Figure 16.e Installation & Servicing instructions ATAG iR-Range...
- Page 44 Push the clip on top of the electrode upwards and take away the electrode; Remove and replace the gasket; Reassembly takes place in reverse order. Always replace the gaskets of the removed parts during maintenance. Put the boiler back into operation and carry out a flue gas analysis (see page 34). Installation & Servicing instructions ATAG iR-Range...
-
Page 45: Component Replacement
User's instructions Advise the user that for continued efficient and safe operation, the boiler should be serviced at least once a year by qualified servicing company. It is important and strongly recommended that arrangements are made for a maintenance agreement with a qualified servicing company to ensure regular servicing of the boiler. Please contact ATAG Heating Technology Ltd. for further details. Contact details can be found on the back page of this manual. 16.3 Maintenance frequency ATAG Heating Technology Ltd advises an annual inspection or every 1600 running hours, with a full strip down service as required, every 4 years or every 6400 running hours, whatever comes first. -
Page 46: Error Codes And Fault Finding
Fan error (speed control is not achieved or is out of range) or control unit defective 154 Flow increases to fast ∆T to large, return > flow No error: shortly visible when leaving chimney sweep function No error: shortly visible when leaving commissioning mode Example of display of error message Installation & Servicing instructions ATAG iR-Range... -
Page 47: Annex A System Water Additives
ATAG support the use of inhibitors suitable for mixed metal applications that keep the pH level between 6 and 8. Dosage levels as per manufacturers instructions. Preferred inhibitor suppliers are ATAG Heating Technology, Fernox and Sentinel. -
Page 48: Annex B Declaration Of Conformity
Annex B Declaration of conformity CE DECLARATION OF CONFORMITY Hereby declares ATAG Verwarming Nederland BV that, the condensing boiler types: ATAG iR 12 iR 32 iR 15 iR 40 iR 18 iR 24 are in conformity with the provisions of the following EC Directives, including all amendments, and... -
Page 49: Annex C Short Parts List
Annex C Short parts list Installation & Servicing instructions ATAG iR-Range... - Page 50 Installation & Servicing instructions ATAG iR-Range...
- Page 51 Installation & Servicing instructions ATAG iR-Range...
- Page 53 Benchmark Commissioning and Servicing Section It is a requirement that the boiler is installed and commissioned to the manufacturers instructions and the data fields on the commissioning checklist completed in full. To instigate the boiler guarantee the boiler needs to be registered with the manufacturer within one month of the installation.
- Page 54 GAS BOILER SYSTEM COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the boiler as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failuretoinstallandcommissionaccordingtothemanufacturer’sinstructionsandcompletethisBenchmarkCommissioningChecklistwillinvalidatethe warranty.Thisdoesnotaffectthecustomer’sstatutoryrights.
- Page 55 SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider BeforecompletingtheappropriateServiceRecordbelow,pleaseensureyouhavecarriedouttheserviceasdescribedinthemanufacturer’sinstructions. Alwaysusethemanufacturer’sspecifiedsparepartwhenreplacingcontrols. SERVICE 01 SERVICE 02 Date: Date: Engineername: Engineername: Companyname: Companyname: TelephoneNo: TelephoneNo: GassaferegisterNo: GassaferegisterNo: Atmax.rate: COppm AND CO ²...
- Page 56 A T A G H e a t i n g T e c h n o l o g y L t d . • C a s t l e S t r e e t • R e a d i n g •...
