I n s t a l l a t i o n & S e r v i c i n g
Natural Gas Boilers
Boiler
G.C No
iR 15
41-310-32
iR 18
41-310-34
iR 24
41-310-36
iR 32
41-310-38
iR 40
41-310-40
CE PIN 0063CQ3634
These instructions are to be retained by the user.
Instructions
Propane Gas Boilers
Boiler
G.C No
iR 15 LPG
41-310-33
iR 18 LPG
41-310-35
iR 24 LPG
41-310-37
iR 32 LPG
41-310-39
iR 40 LPG
41-310-41
iR 15
iR 18
iR 24
iR 32
iR 40
Open Vent System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iR 15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atag iR 15

Summary of Contents for Atag iR 15

  • Page 1 40 Open Vent System Natural Gas Boilers Propane Gas Boilers Boiler G.C No Boiler G.C No iR 15 41-310-32 iR 15 LPG 41-310-33 iR 18 41-310-34 iR 18 LPG 41-310-35 iR 24 41-310-36 iR 24 LPG 41-310-37 iR 32...
  • Page 2 Press 6 seconds for Information Reset button reset DHW button +/-function (ancillary function: Scroll and +/-function) Commissioning function (Press both + buttons for 6 seconds) See chapter 12 for more information about button functions and read-out. Installation & Servicing instructions ATAG iR-Range...

  • Page 3: Table Of Contents

    Electrical connection ........................30 10.1 Bus connection .........................31 10.2 Room thermostat volt free connection ................31 10.3 ATAG Central Heating volt free timer connection ..............31 10.4 ATAG Hot Water volt free timer connection ..............31 10.5 DHW sensor connection ....................31 10.6 ATAG Outside sensor ......................31 10.7...

  • Page 4: Introduction

    These instructions are intended for the use of Gas Safe registed installers in connection with the installation and putting into operation of ATAG boilers. It is advisable to read these instructions thoroughly, well in advance of installation. Separate instructions for use are supplied with the boiler for users of ATAG central heating boilers.

  • Page 5: Rules & Regulations (Symbols)

    Installation Manual. Manufacturers instructions must not be taken, in any way, as overriding statutory obligations. The ATAG iR boiler is a central heating boiler for "open" expansion tank systems (open vent) only. The boiler must be connected according to these instructions and all installation norms in respect of the part of the boiler to be connected.
  • Page 6 Transport and place the boiler in its packaging in this position. Do not to step on or stand on the package. An assembly or dismantling must be carried out. Pay extra attention in connection with a particular operation. Useful tip or advice Installation & Servicing instructions ATAG iR-Range...

  • Page 7: Technical Specifications

    (GCV) η efficiency at 30% of the nominal heat input (GCV) 0.023 0.028 0.036 0.040 0.046 0.005 0.005 0.005 0.005 0.005 0.004 0.004 0.004 0.004 0.004 heat loss 0.055 0.055 0.055 0.055 0.055 stby Installation & Servicing instructions ATAG iR-Range...

  • Page 8: Dimensions

    Dimensions ATAG iR-Series Regular iR 15 iR 18 iR 24 iR 32 iR 40 Flue gas / Air intake 60/100 Gas connection CH Flow connection CH Return connection Condensate drain connection 21.5 Installation & Servicing instructions ATAG iR-Range...

  • Page 9: Delivery Package

    External controls. Boiler description The ATAG iR is a room sealed, condensing and modulating CH boiler for "open" expansion tank systems (open vent) only. The boiler is equipped with a compact stainless steel heat exchanger with smooth pipes. It is a well thought- out principle using sustainable materials.

  • Page 10: Boiler Photo Components List

    Boiler data plate Flow switch Air supply damper Siphon Gas pipe Gas valve 13 Isolation valve flow CH Flow pipe CH Automatic de-aerator Isolation valve gas Return pipe CH Control unit Isolation valve return CH Condensation pipe Control panel Installation & Servicing instructions ATAG iR-Range...

  • Page 11: Mounting Boiler Frame

    (when present) when placing back the boiler front panel and take care the wire does not get stuck between front panel and boiler. Always replace and turn the 2 screws tight in the fasteners A and B. Service space Service space Service dimensions (in mm) Figure 8.a See chapter 9.8 for further procedure to fit the boiler onto the boiler frame. Installation & Servicing instructions ATAG iR-Range...

  • Page 12: Wall Frame

    2.5 mm MINIMAL SIDE CLEARANCE MINIMAL SIDE CLEARANCE = 395 mm = Maximum straight length: 18 m : iC 24/28/ Economiser 27 iR 15/18/24 iS 15/18/24 6 m : iC 36/40/ 39 iR 32/40 iS 32/40 Economiser Economiser 749mm 854mm...

  • Page 13: Connecting Boiler

    Connect the central heating system according to the current regulations. Open vent heating system 450 mm Recommended relationship Min. height between pump, cold feet and vent. cylinder 1000 mm Min. Heating circuit Pump Boiler 150 mm Max. Scheme open vent system Figure 9.1.a Installation & Servicing instructions ATAG iR-Range...

  • Page 14: Water Quality

    The warranty becomes invalid, if the installation is not being flushed and/or the quality of the filling water does not meet the specifications recommended by ATAG Heating Technology Ltd. Always contact ATAG Heating Technology Ltd in advance, if things are not clear or you wish to discuss any deviations. Without approval, the warranty becomes invalid.

  • Page 15: Heating Systems With Plastic Pipes

    No recourse can be made to the terms of the warranty in the event of failure to observe the regulations pertaining to plastic underfloor heating pipes. Installation & Servicing instructions ATAG iR-Range...

  • Page 16: Gas Connection In General

    ATAG supplies boilers suitable for natural gas only and boilers for LPG only. Verify the identification plate on the boiler if the boiler is suitable for the gas kind on site. The boilers cannot be converted to another kind of gas.

  • Page 17: House Pressure Regulator

    In case of a discharge the gasses will go outside. If fitting the regulator outside the regulator should be protected against influences of the weather. The (de-) aeration must be positioned downwards (see figure 9.5.3.a). ATAG advices to install measure points on all gas line parts to have the possibility to check for pressure loss. example propane installation figure 9.4.3.a Pre-pressure must be adjusted to 37 mbar by means of the house pressure regulator. The maximum permitted closing pressure may be 5 mbar higher than the maximum pre-pressure.

  • Page 18: Condensation Drain Pipe

    (b) an internal kitchen or bathroom waste pipe, washing machine waste pipe etc. Figure 9.5.3 shows a typical connection method. A suitable permanent connection to the foul waste pipe should be used and the manufacturer’s detailed installation instructions for the pump should be followed. Installation & Servicing instructions ATAG iR-Range...
  • Page 19 45° Minimum internal diameter 19mm (fall at least 45mm per meter) 7 Pipe size transition Minimum internal diameter 30mm Water/weather proof insulation Drain requirements Figure 9.5.2 (b) Drain requirements Figure 9.5.3 Installation & Servicing instructions ATAG iR-Range...
  • Page 20 Draining of the condensation water to the external rain guttering is not permitted in view of the danger of freezing. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iR-Range...
  • Page 21 Minimum internal diameter 19mm (fall at least 45mm per meter) 8 Pipe size transition point 9 Pipe size transition point Minimum internal diameter 30mm 10 Minimum internal diameter 30mm 10 Water/weather proof insulation 11 Water/weather proof insulation Drain requirements Figure 9.5.7 Drain requirements Figure 9.5.6 Installation & Servicing instructions ATAG iR-Range...

  • Page 22: Flue Gas Exhaust System

    - Air supply pipe; - Roof or wall terminal. The flue gas exhaust system and air supply system must comply with: The flue gas outlet and air supply installation must comply with the current regulation requirements in accordance with BS:5440 Part 1 and 2. The ATAG iR boiler as described in this manual is NOT suitable for a combined flue system. The appliance concentric connection diameter is 60/100 mm, to which the flue gas outlet and air supply system can be fitted, with or without elbow pieces. The maximum permissible pipe length is set out in Table 9.6.2.a. For further information about the available components of the flue gas and air supply system we recommend you consult the Flue system literature. Combinations with other brands or systems are, without written permission from ATAG Heating, not permitted.

  • Page 23: Flue Terminal Locations

    Figure 9.6.1.a Maximum straight length for 60/100: Ø 18 m : iC 24/28/ 27 iR 15/18/24 iS 15/18/24 Economiser 6 m : iC 36/40/ 39 iR 32/40 iS 32/40 Economiser Economiser 959mm...
  • Page 24 In certain weather conditions the terminal will emit a plume of steam. If possible avoid positioning the terminal where this may cause a nuisance, i.e. positions A, D, G, H, J or M. 7. The flue terminal must be exposed to the external air and the position must allow the free passage of air across it at all times. 8. A terminal must not be sited below 2m where people have access to, such as public footpaths, access routes, patios etc. However, If the terminal is fitted less than 2m above a surface where there is no public access, the terminal must be protected by a terminal guard. Installation & Servicing instructions ATAG iR-Range...
  • Page 25 BS 5440: Part 1 recommends that care is taken when siting terminals in relation to boundaries. Notes: See also Notes on previous page. 2. Plume kits running horizontally must have a 10° fall back to the boiler for proper disposal of condensate. 3. For details on specific lengths see relevant chapter Dimensioning of the flue gas and air intake duct. A terminal must not be sited under a car port roof. Installation & Servicing instructions ATAG iR-Range...

  • Page 26: Dimensioning Of The Flue Gas And Air Intake Duct

    When using bends the noted value behind every bend should be deducted from the maximum straight length. Dimensions flue gas system and air supply system Concentric flue system ø60/100 (Horizontal & Vertical) Type iR 15 iR 18 iR 24 iR 32 iR 40 Maximum equivalent length (L) m 45° bend resistance length -1.0 -1.0 87°...
  • Page 27 When mounting the flue gas system, pay attention to the flow direction (See figure 9.6.2.b). It is not permitted to mount a system upside down and will lead to complaints. Use a soap solvent or special grease (supplied in the accessory bag with the boiler) to simplify the fitting. The ATAG flue system used is a push fit flue system, which does not require screws to be fitted at each flue joint. The flue system must be adequately supported at regular intervals between brackets of no more than 1.0 metres for horizontal sections and no more than Flow direction Figure 9.6.2.b 2.0 metres for vertical sections. Installation & Servicing instructions ATAG iR-Range...

  • Page 28: Fitting The Boiler Onto The Boiler Frame

    1. Press all connection underneath the boiler upwards 2. Put on each valve and the elbow fitting a fibre washer (supplied) ± 50mm Figure 9.7.b 3 and 4. Take the boiler and hang it from approx. 50mm higher than the boiler frame vertical downwards on the boiler frame so the fittings will be axial approached. Installation & Servicing instructions ATAG iR-Range...
  • Page 29 (10). NOTE: The plug remains closed when the flexible transparent tube from the automatic deaerator is not connected. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iR-Range...

  • Page 30: Electrical Connection

    - No changes may be made to the wiring of the appliance; - All connections should be designed in accordance with the enclosed regulations; - Should it be necessary to change it, the mains power supply cable may only be replaced with an ATAG mains power supply cable.

  • Page 31: Bus Connection

    BUS connection (blue) N/A not applicable. 10.2 Room thermostat volt free connection (black) N/A not applicable. 10.3 ATAG Central Heating volt free timer connection (white) N/A not applicable. 10.4 ATAG Hot Water volt free timer connection (white) N/A not applicable.

  • Page 32: Electrical Diagram

    10.10 Electrical diagram Figure 10.1.a Installation & Servicing instructions ATAG iR-Range...

  • Page 33: Filling System

    5 minutes if there is still a demand from the heating. 1.320 2.318 1.268 2.159 1.218 2.013 The ATAG iR is equipped with boiler sensors of 10kOhm. The resistance 1.170 1.878 value and corresponding temperature are shown in the accompanying 1.125 1.753 1.081 1.638...

  • Page 34: Controls And Explanation Of The Functions

    See chapter 17 for a brief overview of codes Ancillary functions: °C Both + buttons = Commissioning-mode for checking the CO CH + button = OK (confirm) (OK) DHW Button: Scroll function (‘scrolling’ through parameters) CH – button = ESC function reset (ESC) (back to standard display) Installation & Servicing instructions ATAG iR-Range...

  • Page 35: Commissioning The Boiler

    (software version part 1 and software version part 2) The code 105 appears on the display; The 7 minute de-aeration cycle starts; This will take approx. 7 minutes and will be followed by the default display (OK). The iR boilers are supplied with a flow switch. If the external pump starts, the flow switch is made, the burner is set free, if the flow switch not made the boiler will not fire. Installation & Servicing instructions ATAG iR-Range...
  • Page 36 By pressing both - buttons at the same time for 8 seconds the pump can be switched on continuously. If the pump is set to continuously this is displayed by Boiler frost protection If the (T1) flow sensor registers a temperature of 5°C or below in the boiler, the boiler will fire up. The boiler keeps on firing until the temperature reaches 10°C (measured on the flow sensor) and the boiler switches off again. In this mode the symbol will flash. Installation & Servicing instructions ATAG iR-Range...

  • Page 37: Settings

    Boiler type. Do not change! 1 = Natural gas fired boiler, 2 = Boiler with flue non-return valve, 3 = Propane gas fired boiler Service-parameter. Do not change! * Depending of connected type of boiler control Installation & Servicing instructions ATAG iR-Range...

  • Page 38: Isolating The Boiler

    Switching on with the + button takes place in reverse order. reset ATAG recommends to leave the electrical power supply on, so that the circulation pump is activated automatically once every 24 hours in order to prevent jamming. If there is danger of frost it is advisable in this case to drain the boiler and/or installation. (See following chapter) Installation &...

  • Page 39: Commissioning

    Always check all gas carrying parts for leaks (with a leak detection spray) after (maintenance) work to the boiler. Close the relevant commissioning valves during the maintenance activities. See figure 15.a. Draining the boiler The heating installation must be provided with a fill and drain valve. Use this feature also for draining the boiler. CH FLOW CH RETURN OPEN CLOSED Figure 15.a Installation & Servicing instructions ATAG iR-Range...

  • Page 40: Checking The Co

    (see Step 3 on page 41). check on full load (Step 1) Full load Natural gas (G20) Propane (G31) Nominal 9,0% Nominal 10,3% Minimum 8,6%, maximum 9,6% Minimum 9,9%, maximum 11,0% Values are valid with closed cover/air box. Installation & Servicing instructions ATAG iR-Range...
  • Page 41 CO value at full load. The measuring procedure must be carried out, until a constant measuring result is achieved. Please contact ATAG, if the values should lie outside of the applicable tolerances.
  • Page 42 Adjustment of the gas valve in case the measured values lies out of range of the values on full load (Step 3) Full load Natural gas (G20) Propane (G31) 9,0% 10,3% Values are valid with closed cover/air box. Installation & Servicing instructions ATAG iR-Range...

  • Page 43: Checking Flue Integrity

    - If the readings are outside these limits then this indicates that there is a problem with the flue system or combustion circuit, e.g. missing or dislodged seals. End of measuring: - Press the ESC button ( button). The device switches off. The display shows for 2 seconds code 180 or 181. This completes the procedure. Installation & Servicing instructions ATAG iR-Range...

  • Page 44: Co And Combustion Checks

    The installer should verify that flue integrity has been visually checked in accordance with the yellow “Prior to CO and combustion ratio check” box above before proceeding to the “Check CO and combustion ratio at maximum rate” stage below. To next page Installation & Servicing instructions ATAG iR-Range...
  • Page 45 BOILER IS OPERATING SATISFACTORILY No further actions required. Ensure test points are capped, boiler case is correctly replaced and all other commissioning procedures are completed. Complete Benchmark Checklist, recording CO and combustion ratio readings as required. Installation & Servicing instructions ATAG iR-Range...

  • Page 46: Routine Servicing

    16 Routine servicing ATAG Heating Technology advises on an interim service inspection with a flue gas analyser. A full strip down service is recommended at regular intervals or where analyser readings are not within correct safety standards. Required tools: Cross head screwdriver...
  • Page 47 Check the burner cassette for wear and tear, pollution and any breakages. Clean the burner cassette with a soft brush and vacuum cleaner. In the case of breakages, always replace the complete burner cassette (8); Installation & Servicing instructions ATAG iR-Range...
  • Page 48 TOP-FLUSHING THE EXCHANGER WITH WATER IS NOT ALLOWED. OPEN Reassembly takes place in reverse order. During installation pay attention to the correct position of the clamp bars. HEX KEY These have to be in a vertical position. CLOSED Installation & Servicing instructions ATAG iR-Range...

  • Page 49: Component Replacement

    A and B. Always replace and turn the 2 screws tight in the fasteners A and B. Please contact your installer or ATAG Heating Technology Ltd. for further details. Contact details can be found on the back page of this manual.

  • Page 50: User's Instructions

    User's instructions Advise the user that for continued efficient and safe operation, the boiler should be serviced at least once a year by qualified servicing company. It is important and strongly recommended that arrangements are made for a maintenance agreement with a qualified servicing company to ensure regular servicing of the boiler. Please contact ATAG Heating Technology Ltd. for further details. Contact details can be found on the back page of this manual. 16.3 Warranty For the warranty conditions we refer to the Warranty Card that is supplied with the boiler.

  • Page 51: Error Codes And Fault Finding

    Flow switch not closed at heat demand (system pump not running) No error: shortly visible when leaving chimney sweep function No error: shortly visible when leaving commissioning mode Example of display of error message Installation & Servicing instructions ATAG iR-Range...

  • Page 52: Annex A System Water Additives

    ATAG support the use of inhibitors suitable for mixed metal applications that keep the pH level between 6 and 8. Dosage levels as per manufacturers instructions. Preferred inhibitor suppliers are ATAG Heating Technology, Fernox and Sentinel.

  • Page 53: Annex B Declaration Of Conformity

    Annex B Declaration of conformity CE DECLARATION OF CONFORMITY Hereby declares ATAG Verwarming Nederland BV that, the condensing boiler types: ATAG iR12 iR15 iR18 iR24 iR32 iR40 are in conformity with the provisions of the following EC Directives, including all amendments, and...

  • Page 54: Annex C Short Parts List

    Silencer iCon 1 & 2 S4847800 Gasket condensate tray iCon1 S4854600 Gasket condensate tray iCon2 S4854700 NTC return S4746000 Fuse T3,15 250V 3pcs S4749200 Clamp bar long S4850900 Flow switch regular S4856200 Flue Gas Non Return Valve AA07400U Installation & Servicing instructions ATAG iR-Range...
  • Page 55 Installation & Servicing instructions ATAG iR-Range...
  • Page 57 Benchmark Commissioning and Servicing Section It is a requirement that the boiler is installed and commissioned to the manufacturers instructions and the data fields on the commissioning checklist completed in full. To instigate the boiler guarantee the boiler needs to be registered with the manufacturer within one month of the installation.
  • Page 58 °C Waterflowrate I/min CONDENSING BOILERS ONLY Thecondensatedrainhasbeeninstalledinaccordancewiththemanufacturer’sinstructionsand/orBS5546/BS6798 ALL INSTALLATIONS Atmax.rate:COppm AND CO/CO ² Ratio Recordthefollowing: Atmin.rate:(wherepossible)COppm AND CO/CO ² Ratio TheheatingandhotwatersystemcomplieswiththeappropriateBuildingRegulations Theboilerandassociatedproductshavebeeninstalledandcommissionedinaccordancewiththemanufacturer’sinstructions Theoperationoftheboilerandsystemcontrolshavebeendemonstratedtoandunderstoodbythecustomer Themanufacturer’sliterature,includingBenchmarkChecklistandServiceRecord,hasbeenexplainedandleftwiththecustomer CommissioningEngineer’sSignature Customer’sSignature (Toconfirmsatisfactorydemonstrationandreceiptofmanufacturer’sliterature) * A llinstallationsinEnglandandWalesmustbenotifiedtoLocalAuthorityBuildingControl(LABC)eitherdirectlyorthrougha CompetentPersonsScheme.ABuildingRegulationsComplianceCertificatewillthenbeissuedtothecustomer. Installation & Servicing instructions ATAG iR-Range ©HeatingandHotwaterIndustryCouncil(HHIC) www.centralheating.co.uk www.centralheating.co.uk...
  • Page 59 CO ² % COppm AND Atmax.rate: CO ² % Record: Record: Atmin.rate: COppm AND CO ² % Atmin.rate: COppm AND CO ² % (WherePossible) (WherePossible) Comments: Comments: Signature Signature * A llinstallationsinEnglandandWalesmustbenotifiedtoLocalAuthorityBuildingControl(LABC)eitherdirectlyorthrougha CompetentPersonsScheme.ABuildingRegulationsComplianceCertificatewillthenbeissuedtothecustomer. Installation & Servicing instructions ATAG iR-Range ©HeatingandHotwaterIndustryCouncil(HHIC) www.centralheating.co.uk...
  • Page 60 A T A G H e a t i n g T e c h n o l o g y L t d . • C a s t l e S t r e e t • R e a d i n g •...
