I n s t a l l a t i o n & S e r v i c i n g
Natural Gas Boilers
Boiler
i24C
i28C
i36C
i40C
iC
Economiser
iC
Economiser
iC
Economiser
CE PIN 0063CQ3634
These instructions are to be retained by the user.
Instructions
G.C No
47-310-36
47-310-37
47-310-38
47-310-39
27
47-310-40
Plus
35
47-310-41
Plus
39
47-310-42
Plus
i24C
i28C
i36C
i40C
iC
Economiser
iC
Economiser
iC
Economiser
27
Plus
35
Plus
39
Plus
Advertisement
Table of Contents
Related Manuals for Atag i28C
Summary of Contents for Atag i28C
- Page 1 I n s t a l l a t i o n & S e r v i c i n g Instructions i24C i28C i36C i40C Economiser Plus Economiser Plus Economiser Plus Natural Gas Boilers Boiler G.C No i24C...
- Page 2 Press to go back one screen RESET button Press to reset a fault code Commissioning Press to enter into service mode which button allows adjustment of high fire/low fire and settings (Do not use. For service purposes only) Installation & Servicing instructions ATAG iC-Range...
- Page 3 10 DHW status symbol. A box around the tap symbol indicates DHW is in operation 11 Visual illustration of current hot water temperature. Scale changes as the set temperature is changed See chapter 12 for more information about button functions and read-out. Installation & Servicing instructions ATAG iC-Range...
-
Page 4: Table Of Contents
System water additives ........................74 Annex B Declaration of conformity ........................75 Annex C Short parts list ...........................76 Work on the installation should only be carried out by qualified personnel with calibrated equipment and appropriate tools. Installation & Servicing instructions ATAG iC-Range... -
Page 5: Introduction
ATAG boilers. It is advisable to read these instructions thoroughly, well in advance of installation. Separate instructions for use are supplied with the boiler for users of ATAG central heating boilers. ATAG is not liable for the consequences of mistakes or shortcomings which have found their way into the installation instructions or user’s manual. -
Page 6: Rules & Regulations (Symbols)
British Standards. The ATAG iC boiler is a certified appliance and must not be modified or installed in any way contrary to this Installation Manual. Manufacturers instructions must not be taken, in any way, as overriding statutory obligations. - Page 7 Your cooperation in the proper disposal of this product will contribute to the effective usage of natural resources. For more information on recycling this product, please contact your city office, local waste disposal facilities, official service for chemical waste or landfill site. Installation & Servicing instructions ATAG iC-Range...
-
Page 8: Technical Specifications
19.1 - 28.3 8.3- 21.2 19.1 - 28.3 19.1 - 28.3 Modulation range CH (50/30°C) 9.0 - 23.2 9.0 - 23.2 20.8 - 31.2 20.8 - 31.2 9.0 - 23.2 20.8 - 31.2 20.8 - 31.2 Installation & Servicing instructions ATAG iC-Range... - Page 9 27.315 27.315 25.649 25.122 25.122 Temperature Control Weathercompensator (outside sensor) Class of temperature control Contribution of temperature control Package Seasonal space heating energy efficiency of package CH Package Energy Label DHW Package Energy Label Installation & Servicing instructions ATAG iC-Range...
-
Page 10: Dimensions
ATAG iC-Series i24C i28C i36C i40C Economiser Plus Economiser Plus Economiser Plus Flue gas / Air intake 60/100 Gas connection CH Flow connection CH Return connection Condensate drain connection 21.5 Cold water connection DHW connection Installation & Servicing instructions ATAG iC-Range... -
Page 11: Delivery Package
External controls. Boiler description The ATAG iC is a room sealed, condensing and modulating CH boiler equipped with an integrated hot water supply. The boiler is equipped with a compact stainless steel heat exchanger with smooth pipes. It is a well thought- out principle using sustainable materials. -
Page 12: Boiler Photo Components List
Expansion vessel Flue non return valve Flow sensor Gas pipe Return sensor Flow pipe CH Return pipe CH Hot water sensor DHW flow sensor Condensation pipe Cold water pipe Water pressure sensor Hot water pipe Installation & Servicing instructions ATAG iC-Range... -
Page 13: Mounting Boiler Frame
Always refit and turn the 2 screws tight in the fasteners A and B. Service space Service space *Economiser version only *Economiser version only Service dimensions (in mm) Figure 8.a See chapter 9.8 for further procedure to fit the boiler onto the boiler frame. Installation & Servicing instructions ATAG iC-Range... -
Page 14: Wall Frame
= 380 mm = EXPANSION VESSEL HOSE PASSAGE 65 mm 40 mm 55 mm 95 mm 65 mm = 440 mm = = free space for piping ATAG i-Serie template and iC-Range boiler frame Figure 8.1.a Installation & Servicing instructions ATAG iC-Range... -
Page 15: Connecting Boiler
The boiler is NOT equipped with a built-in internal filter. Advice: ATAG Heating Technology Ltd recommend the installation of an in-line filter installed into the heating return as close to the boiler as possible. ATAG Heating Technology Ltd recommend the use of the: ATAG iGuard Magnetic filter 22mm (Plastic) FC000100, (Brass) FC000200, 28mm (Brass) FC000250. -
Page 16: Expansion Vessel
The warranty becomes invalid, if the installation is not being flushed and/or the quality of the filling water does not meet the specifications recommended by ATAG Heating Technology Ltd. Always contact ATAG Heating Technology Ltd in advance, if things are not clear or you wish to discuss any deviations. Without approval, the warranty becomes invalid. - Page 17 Chemical additions are to be avoided and should only be used after ATAG Heating Technology Ltd has approved their corresponding use. Should you wish to achieve the required water quality by using chemical additives, then this is your own responsibility. The warranty on the product delivered by ATAG Heating Technology Ltd expires, if the water quality does not meet ATAG Heating Technology's specifications or the chemical additives have not been approved by ATAG Heating Technology Ltd.
-
Page 18: Heating Systems With Plastic Pipes
An existing service pipe must NOT be used without prior consultation with the local gas supplier. ATAG supplies boilers suitable for natural gas only. Verify the identification plate on the boiler if the boiler is suitable for the gas kind on site. -
Page 19: House Pressure Regulator
If fitting the regulator outside the regulator should be protected against influences of the weather. The (de-) aeration must be positioned downwards (see figure 9.5.3.a). ATAG advices to install measure points on all gas line parts to have the possibility to check for pressure loss. example propane installation figure 9.5.3.a... -
Page 20: Hot Water Supply
Regulations and Scottish Water Byelaws. The ATAG iC boiler is fitted with a stainless steel plate heat exchanger for producing domestic hot water. The boiler does not have a hot water store and in case of a demand for hot water the boiler will heat the domestic water flowing through the plate heat exchanger up to 60°C (adjustable) instantaneous. - Page 21 45° Minimum internal diameter 19mm (fall at least 45mm per meter) Pipe size transition Minimum internal diameter 30mm 10 Water/weather proof insulation Drain requirements Figure 9.7.2 (b) Drain requirements Figure 9.7.3 Installation & Servicing instructions ATAG iC-Range...
- Page 22 Draining of the condensation water to the external rain guttering is not permitted in view of the danger of freezing. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iC-Range...
- Page 23 Water/weather proof insulation Minimum internal diameter 19mm (fall at least 45mm per meter) Pipe size transition point 10 Minimum internal diameter 30mm 11 Water/weather proof insulation Drain requirements Figure 9.7.7 Drain requirements Figure 9.7.6 Installation & Servicing instructions ATAG iC-Range...
-
Page 24: Flue Gas Exhaust System
ATAG Heating, not permitted. The ATAG flue gas system is meant, and designed, solely for the use on ATAG central heating boilers adjusted to Nat gas or LPG. For this purpose the CE Certificate has been supplemented under the Gastec nr: 0063CQ3634 The maximum flue gas temperatures are below 70°C (full load 80/60°C). -
Page 25: Flue Terminal Locations
See figure 9.8.1.b. Figure 9.8.1.a Maximum straight length for 60/100: Ø 15 m : i24C/i28C iC i15R/i18R/i24R i15S/i18S/i24S Economiser Plus 9 m : i36C/i40C i32R/i40R i32S/i40S 8 m : iC... - Page 26 A terminal must not be sited below 2m where people have access to, such as public footpaths, access routes, patios etc. However, If the terminal is fitted less than 2m above a surface where there is no public access, the terminal must be protected by a terminal guard. Installation & Servicing instructions ATAG iC-Range...
- Page 27 Plume kits running horizontally must have a 10° fall back to the boiler for proper disposal of condensate. For details on specific lengths see relevant chapter Dimensioning of the flue gas and air intake duct. A terminal must not be sited under a car port roof. Installation & Servicing instructions ATAG iC-Range...
-
Page 28: Dimensioning Of The Flue Gas And Air Intake Duct
2 x 45° bends, so the maximum flue gas length is 15 – ( 2 x -1.3 ) = 12.4m. Flue dimensions Rear Flue B (mm) Telescopic flue (FA100105) Side Flue B + C (mm) Telescopic flue (FA100105) Installation & Servicing instructions ATAG iC-Range... - Page 29 Use the special grease (supplied in the accessory bag with the boiler) to simplify the fitting. The ATAG flue system used is a push fit flue system, which does not require screws to be fitted at each flue joint. The flue system must be adequately supported at regular intervals between brackets of no more than 1.0 metres for horizontal sections and no more than...
-
Page 30: Fitting The Boiler Onto The Boiler Frame
± 50mm Figure 9.9.b 3 and 4. Take the boiler and hang it from approx. 50mm higher than the boiler frame vertical downwards on the boiler frame so the fittings will be axial approached. Installation & Servicing instructions ATAG iC-Range... - Page 31 (10). NOTE: The plug remains closed when the flexible transparent tube from the automatic deaerator is not connected. Before putting the boiler into operation fill the siphon with 150 ml of water. Installation & Servicing instructions ATAG iC-Range...
-
Page 32: Electrical Connection
- No changes may be made to the wiring of the appliance; - All connections should be designed in accordance with the enclosed regulations; - Should it be necessary to change it, the mains power supply cable may only be replaced with an ATAG mains power supply cable. -
Page 33: External Safety Contact
10.4 ATAG Zone connection (red) The ATAG One zone smart room thermostat is the primary candidate for use of the ATAG zone eBus connection. The smart room thermostat can also be substituted by another ATAG zone compatible room controller, this eBus enables the boiler to modulate set point temperatures for optimal efficiency. - Page 34 If an external pump needs to be controlled and switched on when heating mode is operating on the boiler, 230v power (outlet) can be used to power an external pump on the system. (optional extra plug required) Installation & Servicing instructions ATAG iC-Range...
-
Page 35: 230V Out (230V Live Output)
230V out 230V in 230V out 230V Control RETURN SENSOR T2 FLOW SENSOR T1 OPEN THERM OR ON/OFF THERMOSTAT (OPTION) ATAG ZONE (OPTION) OUTDOOR SENSOR T4 (OPTION) OUTSIDE THE BOILER TOP HMI Figure 10.7.a Installation & Servicing instructions ATAG iC-Range... -
Page 36: Filling System
5 Vent the entire heating installation starting at the lowest point; 6 Check the water pressure and top up if necessary to 1.0 – 1.2 bar; 7 Check the filling loop valve is closed; OPEN CLOSED Figure 11.a Installation & Servicing instructions ATAG iC-Range... -
Page 37: Hot Water Supply
Bleed the hot water installation by opening all hot water taps one at a time. Leave each tap to run until all air has disappeared from the supply. Flush with a minimum of 10 litres to rinse any residual contaminants from the hot supply and boiler. Installation & Servicing instructions ATAG iC-Range... -
Page 38: Boiler Controls
5 minutes if there is still a demand from the heating. 2.857 9.573 2.730 8.779 2.610 8.059 The ATAG iC is equipped with boiler sensors of 10kOhm. The resistance 2.496 7.406 2.387 6.811 value and corresponding temperature are shown in the accompanying 2.284 6.271... - Page 39 Central heating status symbol. A box around Pump continuous/frost protection the radiator symbol indicates central heating is in operation Burner on Hot water is not preheated Hot water is pre-heated and kept hot COMFORT Installation & Servicing instructions ATAG iC-Range...
-
Page 40: Change The Domestic Hot Water Setpoint Temperature
Option DHW Comfort Setpoint Temp is highlighted. Press OK. The current DHW comfort Setpoint temperature is displayed. Press OK. Turn the selector wheel until the desired temperature appears on the screen. Press OK. Available temperature settings: 10˚C - 65˚C Installation & Servicing instructions ATAG iC-Range... -
Page 41: Change The Central Heating Setpoint Temperature
Option T set Z1 is highlighted. Press OK. Note: T set Z2 and T set Z3 are inactive functions. Turn the selector wheel until the desired temperature appears on the screen. Press OK. Available temperature settings: 20˚C - 80˚C Installation & Servicing instructions ATAG iC-Range... -
Page 42: Change The Domestic Hot Water Comfort Mode Setting
The boiler operates and produces hot water; however, it will not maintain the primary heat exchanger temperature for quicker hot water production. This selection saves some energy, but requires longer time to provide hot water to the hot water fixtures (ECO mode will be displayed on the home screen). Installation & Servicing instructions ATAG iC-Range... -
Page 43: Always Active
Turn the selector wheel to highlight Comfort function. Press OK. Turn the selector wheel to highlight Always Active. Press OK. The message in the screen left appears. The Always Active comfort mode is now selected. Installation & Servicing instructions ATAG iC-Range... -
Page 44: Time Based
Turn the selector wheel to highlight Time Based. Press OK. The message in the screen left appears. Press the Back button one time. The screen on the left appears. Turn the selector wheel to highlight Time program. Press OK. Installation & Servicing instructions ATAG iC-Range... - Page 45 You then select the days with the same time program. Use the selector wheel to scroll to the day(s) you want the same. Select "OK" on each day that will have the same schedule. Installation & Servicing instructions ATAG iC-Range...
-
Page 46: Disabled
Turn the selector wheel to highlight DHW Settings. Press OK. Turn the selector wheel to highlight Comfort function. Press OK. Option Disabled is highlighted. Press OK. The message in the screen left appears. Comfort mode is now disabled. Installation & Servicing instructions ATAG iC-Range... -
Page 47: Change The Language On The Screen
Press OK. Turn the selector wheel to highlight Screen Settings. Press OK. Option Language is highlighted. Press OK. Turn the selector wheel to highlight the desired language. Press OK. The language is changed now. Installation & Servicing instructions ATAG iC-Range... -
Page 48: Change The Time And Date
The relevant field starts to flash. Turn the selector wheel to to select the correct value. Press OK. After correctly filled in all fields, Press Save. The message in the screen left appears. The settings are saved. Installation & Servicing instructions ATAG iC-Range... -
Page 49: Change Units Of Measurement
Turn the selector wheel to highlight Screen Settings. Press OK. Turn the selector wheel to highlight System measurement unit. Press OK. Option International system is highlighted. Press OK. The message in the screen left appears. Installation & Servicing instructions ATAG iC-Range... -
Page 50: Boiler Information
As an example we take the CH Flow Set T. Turn the selector wheel to highlight 8 Service Parameters. Press OK. Option 8.3 Boiler Temperature is highlighted. Press OK. Option 8.3.0 CH Flow Set T is highlighted. Press OK. The screen left appears. Installation & Servicing instructions ATAG iC-Range... - Page 51 CH Flow T in °C 8.3.2 CH Return T in °C 8.3.3 DHW Flow T in °C 8.3.5 Outdoor T (only if an outside sensor is connected) in °C 8.7.5 Ionization current in µA Installation & Servicing instructions ATAG iC-Range...
-
Page 52: Pump Function
If the (T1) flow sensor registers a temperature of 5°C or below in the boiler, the boiler will fire up. The boiler keeps on firing until the temperature reaches 10°C (measured on the flow sensor) and the boiler switches off again. Installation & Servicing instructions ATAG iC-Range... -
Page 53: Commissioning The Boiler
Between 0.5 and 0.8 bar and the boiler will reduce Tset max by 5°C. The automatic air purge program will take approx. 7 minutes and will be followed by the home screen if the water pressure is above 0.8 bar. Installation & Servicing instructions ATAG iC-Range... - Page 54 If the CH water from the system and boiler needs to be drained, open the CV isolation valve (2) Reassembly takes place in reverse order. OPEN CLOSED CH FLOW CH RETURN Figure 15.b OPEN CLOSED Installation & Servicing instructions ATAG iC-Range...
-
Page 55: Checking The Co
Full load Natural gas (G20) Propane (G31)* Nominal 9.0% Nominal 10.3% Minimum 8.6%, maximum 9.6% Minimum 9.9%, maximum 11.0% * Only possible if LPG conversion kit is installed! Values are valid with closed cover/air box. Installation & Servicing instructions ATAG iC-Range... - Page 56 CO value at full load. The measuring procedure must be carried out, until a constant value is achieved. Please contact ATAG, if the values should lie outside of the applicable tolerances.
- Page 57 Adjustment of the gas valve in case the measured values lies out of range of the values on full load (Step 3) Full load Natural gas (G20) Propane (G31)* 9.0% 10.3% * Only possible if LPG conversion kit is installed! Values are valid with closed cover/air box. Installation & Servicing instructions ATAG iC-Range...
-
Page 58: Co And Combustion Checks
“Prior to CO and combustion ratio check” box above before proceeding to the “Check CO and combustion ratio at maximum rate” stage below. To next page Installation & Servicing instructions ATAG iC-Range... - Page 59 BOILER IS OPERATING SATISFACTORILY No further actions required. Ensure test points are capped, boiler case is correctly refit and all other commissioning procedures are completed. Complete Benchmark Checklist, recording CO and combustion ratio readings as required. Installation & Servicing instructions ATAG iC-Range...
-
Page 60: Parameter Chapter
The screen left appears. Turn the selector wheel to highlight Complete Menu. Press OK. It takes a while to load the Menu The screen left appears. This way you have access to the complete parameter level. Installation & Servicing instructions ATAG iC-Range... -
Page 61: Parameter Listing
0 ‐ 1 Test & Utilities 2.7.0 Test mode Chimney sweeper fucntion active 0 = OFF 1 = ON 0 ‐ 1 2.7.1 Air purge Air purge function activation 0 ‐ OFF 1 = ON 0 ‐ 1 2.7.3 Force backup 0 = OFF 1 ‐ ON 0 ‐ 1 2.7.6 Force restore 1 = OFF 1 ‐ ON 0 ‐ 1 Reset Menu 2.8.0 Reset factory settings OK = Yes ESC = No Others 2.9.0 GPI function Selected input for GPI function 0 ‐ 2 0 = Burner block NO 1 = Burner block NC 2 = DHW Timer 2.9.1 Building Frost protection 0 = OFF 1 = ON 0 ‐ 1 Installation & Servicing instructions ATAG iC-Range... - Page 62 8.4.0 n.a. 8.4.2 n.a. Service 8.5.0 Months to next maitenance Months to go before next Maintenance warning comes up 0‐60 8.5.1 Maintenance warning active switch on or of the maintenance warning 0 = OFF 1 = ON 0 ‐ 1 8.5.2 Maintenance warning reset Reset the maintenance warning in the display and the timer 0 ‐ 1 Error History 8.6.0 Error history overview of the last 10 errors occured 8.6.1 Reset Error list OK = Yes ESC = No Free Parameter 8.7.5 Ionization Current 8.7.6 Safety Flame Sensor burner status of the boiler 0 = OFF 1 = ON 8.7.7 CH Flow switch State 0 = OFF 1 = ON Installation & Servicing instructions ATAG iC-Range...
-
Page 63: Weather Compensation
To set the boiler to weather compensation, please set parameter 4.2.1 to 3 with an ON/OFF or OpenTherm controler or to 4 with an ATAG ONE zone or ATAG Cube. Turn the selector wheel to highlight the Parameters Zone you want to set. -
Page 64: Setting The Weather Compensation
Make a choise between: 0 Small or 1 Average or 2 Large Turn the selector wheel to highlight 4.7.1 Room Influence. Press OK. Turn the selector wheel to set the Room Influence 0 OFF. Installation & Servicing instructions ATAG iC-Range... - Page 65 Hea�ng Type Radiators (main) + floor Building Isola�on Level Good Building size Average e. Hea�ng Type Underfloor Building Isola�on Level Average Building size Average Hea�ng Type Underfloor Building Isola�on Level Good Building size Average Installation & Servicing instructions ATAG iC-Range...
-
Page 66: Routine Servicing
15 Routine servicing ATAG Heating Technology advises on an interim service inspection with a flue gas analyser. A full strip down service is recommended at regular intervals or where analyser readings are not within correct safety standards. Required tools: Cross head screwdriver;... -
Page 67: Full Service
After servicing, complete the relevant Service Interval Record section of the Benchmark Checklist located on the inside back page of this document. Where a full service is required the following steps must be followed: Carry out the actions as described in section 15.1 Interim Service. Installation & Servicing instructions ATAG iC-Range... - Page 68 Check the burner cassette for wear and tear, pollution and any breakages. Clean the burner cassette with a soft brush and vacuum cleaner. In the case of breakages, always replace the complete burner cassette (8); Installation & Servicing instructions ATAG iC-Range...
- Page 69 TOP-FLUSHING THE EXCHANGER WITH WATER IS NOT ALLOWED. OPEN Reassembly takes place in reverse order. During installation pay attention to the correct position of the clamp bars. HEX KEY These have to be in a vertical position. CLOSED Installation & Servicing instructions ATAG iC-Range...
- Page 70 Perform the ‘Full Service’. Perform ‘Setting the Gas Valve’. Please contact your installer or ATAG Heating Technology Ltd. for further details. Contact details can be found on the back page of this manual. After servicing, complete the relevant Service Interval Record section of the Benchmark Checklist located on the inside back page of the document.
-
Page 71: Flow Restrictor
It is important and strongly recommended that arrangements are made for a maintenance agreement with a qualified servicing company to ensure regular servicing of the boiler. Please contact ATAG Heating Technology Ltd. for further details. Contact details can be found on the back page of this manual. -
Page 72: Error Codes And Fault Finding
Too many resets No flame detected Fan error (fan does not start up) Example of screen of error message * First measure to solve fault code 140: Manually deblocking of the boiler pump. No. 2 Installation & Servicing instructions ATAG iC-Range... -
Page 73: Reset A Fault Code
- Press OK to reset the error, otherwise the previous screen is shown. The Reset in Progress message appears. After a while the Fault Solved message appears. After the code is reset, the Home screen appears. Installation & Servicing instructions ATAG iC-Range... -
Page 74: View Error Code History
Turn the selector wheel to highlight 8.6 Error History. Press OK. The screen left appears. Option 8.6.0 Last 10 Errors is highlighted. Press OK. A survey of the last 10 Errors appears. An example of an error message on the left. Installation & Servicing instructions ATAG iC-Range... -
Page 75: Annex A System Water Additives
ATAG support the use of inhibitors suitable for mixed metal applications that keep the pH level between 6 and 8. Dosage levels as per manufacturers instructions. Preferred inhibitor suppliers are ATAG Heating Technology, Fernox and Sentinel. -
Page 76: Annex B Declaration Of Conformity
Annex B Declaration of conformity CE DECLARATION OF CONFORMITY Hereby declares ATAG Verwarming Nederland BV that, the condensing boiler types: ATAG i24C i28C i36C i40C iC Economiser 27 Plus iC Economiser 35 Plus iC Economiser 39 Plus are in conformity with the following standards:... -
Page 77: Annex C Short Parts List
Flow Restrictor 10 l/m Yellow S4762000 Flow Restrictor 12 l/m Brown S4748500 Flow Restrictor 15 l/m Blue S4774600 Flow Restrictor 17.5 l/m Green S4779600 Mains water inlet filter S4878200 Flue Gas Non Return Valve AA07400U Installation & Servicing instructions ATAG iC-Range... - Page 78 Gas Safe registered engineer who has been trained on the boiler installed. The service details should be recorded on the Benchmark Service Interval Record and left with the householder. www.centralheating.co.uk Installation & Servicing instructions ATAG iC-Range © Heating and Hotwater Industry Council (HHIC)
- Page 79 °C Waterflowrate I/min CONDENSING BOILERS ONLY Thecondensatedrainhasbeeninstalledinaccordancewiththemanufacturer’sinstructionsand/orBS5546/BS6798 ALL INSTALLATIONS Atmax.rate:COppm AND CO/CO ² Ratio Recordthefollowing: Atmin.rate:(wherepossible)COppm AND CO/CO ² Ratio TheheatingandhotwatersystemcomplieswiththeappropriateBuildingRegulations Theboilerandassociatedproductshavebeeninstalledandcommissionedinaccordancewiththemanufacturer’sinstructions Theoperationoftheboilerandsystemcontrolshavebeendemonstratedtoandunderstoodbythecustomer Themanufacturer’sliterature,includingBenchmarkChecklistandServiceRecord,hasbeenexplainedandleftwiththecustomer CommissioningEngineer’sSignature Customer’sSignature (Toconfirmsatisfactorydemonstrationandreceiptofmanufacturer’sliterature) * A llinstallationsinEnglandandWalesmustbenotifiedtoLocalAuthorityBuildingControl(LABC)eitherdirectlyorthrougha CompetentPersonsScheme.ABuildingRegulationsComplianceCertificatewillthenbeissuedtothecustomer. Installation & Servicing instructions ATAG iC-Range ©HeatingandHotwaterIndustryCouncil(HHIC) www.centralheating.co.uk www.centralheating.co.uk...
- Page 80 CO ² % COppm AND Atmax.rate: CO ² % Record: Record: Atmin.rate: COppm AND CO ² % Atmin.rate: COppm AND CO ² % (WherePossible) (WherePossible) Comments: Comments: Signature Signature * A llinstallationsinEnglandandWalesmustbenotifiedtoLocalAuthorityBuildingControl(LABC)eitherdirectlyorthrougha CompetentPersonsScheme.ABuildingRegulationsComplianceCertificatewillthenbeissuedtothecustomer. Installation & Servicing instructions ATAG iC-Range ©HeatingandHotwaterIndustryCouncil(HHIC) www.centralheating.co.uk...
- Page 81 CO ² % Atmax.rate: COppm AND CO ² % Record: Record: Atmin.rate: COppm AND CO ² % COppm AND Atmin.rate: CO ² % (WherePossible) (WherePossible) Comments: Comments: Signature Signature * A llinstallationsinEnglandandWalesmustbenotifiedtoLocalAuthorityBuildingControl(LABC)eitherdirectlyorthrougha CompetentPersonsScheme.ABuildingRegulationsComplianceCertificatewillthenbeissuedtothecustomer. Installation & Servicing instructions ATAG iC-Range ©HeatingandHotwaterIndustryCouncil(HHIC) www.centralheating.co.uk...
- Page 82 ATAG Heating Technology Ltd. • 80 Churchill Square Business Centre • Kings Hill • West Malling • Kent ME19 4YU P h o n e : 0 8 0 0 2 5 4 5 0 6 1 • E - m a i l : i n f o @ a t a g h e a t i n g .
