- Page 1 HDMI Wireless Extender Model Number: JTD-1263 USER MANUAL...
- Page 2 1. Description This Wireless HD Video Solution enables wireless transmission of video/audio from any HDMI video source , such as PC/HDTV to display devices that includes HDTV/HD Monitor over the 5.8GHz band, with very low latency. It does not require any special configuration of software driver installation-simply connect the transmitter to the HDMI output of the video source and the receiver to the HDMI input of the Panel/TV/Monitor.
-
Page 3: Specifications
Transmission distance will be different due to the environment Wall, brick or glass will shorten the signal cover range or cause big signal loss Specifications Parameter Description Standard Protocol HDMI 1.3; HDCP 1.2 Maximum pixel clock 165MHz Maximum data rate 6.75Gbps 480i@60Hz, 480P@60Hz, 576i@50Hz, Video... - Page 4 Panel Transmitter: Receiver: Port name Description HDMI IN/OUT HDMI signal input/output IR IN/OUT IR signal input/output DC 5V Power adapter socket Display 5.8G frequency band “50”-”59” Channel Back Down UP OK Key Adjust 5.8GHz channel. LED indicator Description Video signal connection indicator (LED on is working ;LED STATUS twinkling is on connection .
- Page 5 1.Back: return the last step. 2.Down: Press “ Down” key , the number display on “ Channel” will be down ,for example “5.8 “ to “5.7” 3. Up: press “ Up” key ,the number display on “ Channel” will be up ,for example “ 5.7” to “ 5.8” 4.
-
Page 6: Installation
Installation 1、 Connect an HDMI cable between the HDMI input port of transmitter and the HDMI output port of the video source, 2、 Connect the HDMI output port of receiver to the display device with HDMI cable, 3、 Connect the provided DC/5V 2A power supplies to the power socket of the transmitter and the receiver, while the “STA”...
