６ Advanced Operation
The LS (remote switch) is set to OFF (invalid) by the startup menu when the product is shipped
from the factory.
When you use the LS (remote switch), set "LS": remote switch to "ON": valid from the startup menu,
then TB1 Pin21 on rear side becomes usable. Use it between attached D-Sub 25-pin male
connectors 10 and 21.
If the remote switch in the startup menu is set to "OFF" (invalid), it becomes also invalid when you
want to reverse the use for floating of ② and the logic of ③.
MATSUSADA Precision Inc.
VOLTAGE
CURRENT
Change ON/OFF of LS
(remote switch) function with
the current setting dial.
40
