Evaluation Board User Guide
Qty Reference Designator
1 R67
1 R69
2 R154, R155
1 R165
1 R166
2 D5, D8
7 GPIO1, GPIO2-T, SCL, SCL-T, SDA,
SDA-T, STROBE
1 J13
1 J12
1 JP8
3 LK1, LK2, LK3
1 JP14
1 J14
2 S2, S3
10 TP17, TP18, TP20 to TP27
1 U1
1 U3
1 U5
1 U7
1 U8
2 U39, U40
1 Y1
Description
Resistor, 180 kΩ, 1%, 0402, SMD
Resistor, 33 kΩ, 1%, 0402, SMD
Resistor, 39 kΩ, 1%, 0603, SMD
Resistor, 48.7 kΩ, 1%, 0603, SMD
Resistor, 97.6 kΩ, 1%, 0603, SMD
LED, 0402, green
Connector header
Connector header, two pins × 1
Connector header, 10 pins × 1
Connector header, 10 pins × 2
Connector header, two pins × 1
Connector receptacle, mini USB2.0,
five-position
Connector header, three pins × 1
Switch pushbutton
Connector header
IC MCU USB peripheral high speed 56-QFN
ADP3303, 3.3 V
IC SRL EEPROM I2C, 64 kB, SO-8
IC 10-bit voltage clamp, 24-TSSOP
ADG734BRUZ, 20-lead TSSOP
ADP1712, five-lead TSOT
Crystal, 24 MHz
Rev. A | Page 15 of 16
Manufacturer/Vendor Part Number
Vishay or equivalent CRCW0402180KFKED
Vishay or equivalent CRCW040233K0FKED
Vishay or equivalent CRCW060339K0FKEA
Vishay or equivalent CRCW060348K7FKEA
Vishay or equivalent CRCW060397K6FKEA
Lumex SML-LX0402SUGC-TR
Sullins Electronics PEC36SAAN
Sullins Electronics PEC36SAAN
Sullins Electronics PEC36SAAN
Sullins Electronics PEC36DAAN
Sullins Electronics PEC36SAAN
Hirose Electronics UX60-MB-5ST
Sullins Electronics PEC36SAAN
C & K components KSC321JLFS or
KT11P3JM34LFS
Sullins Electronics PEC36SAAN
Cypress CY7C68013A-56LFXC
Semiconductor
Analog Devices ADP3303-3.3
STMicroelectronics M24C64
NXP Semiconductors GTL2010PW
Analog Devices ADG734BRUZ
Analog Devices ADP712AUJZ-R7
CTS Electronic CTX651CT
Components
UG-139
