4.1.2 W I T H S W I V E L A R M F R A M E
• If the upright stander has a back support, it must first be removed. (see
chapter „Back support").
• Fold the tray completely forwards or upwards.
To open the frame: Open the star knob
and open the pelvic frame
Make sure that the swivel arm frame does not collide with
persons or objects and that there is sufficient space for the
operation - otherwise there is a risk of injury!
• Position the upright stander as close as possible to the patient and secure
the castors, if present. Secure the patient's seat against rolling away.
• Position the patient's feet in the sandals.
• Initiate the standing procedure until the patient is standing upright.
If possible, the patient can hold on to the tray support in order to
support the process.
When raising the patient, the knee angle should not exceed 90° -
otherwise there is a risk of injury!
The patient must always be supported during the standing
process - otherwise there is a risk of injury!
To close the frame: Swing the swivel arm
engage completely. Close the star knob
table down.
Make sure that the tray does not collide with the patient.
• If available, mount the back support (see chapter „Back support").
4 . 2 H O W T O CO M P L E T E T H E S TA N D I N G T R A I N I N G
4.2.1 W I T H S C I S S O R F R A M E
• If the upright stander has a back support, it must first be removed. (see
chapter „Back support").
• Position the patient's seat as close as possible to the upright stander and
ensure that both the upright stander and the seat are secured against
rolling away (lock castors if present).
• Fold the tray completely forwards or upwards.
The patient must hold on to the frame or be supported by a
person - otherwise there is a risk of injury!
• Open the scissor frame (see chapter „Standing training with swivel arm
frame").
• Lower the patient into the seat.
1023926_EN_0 Subject to technical changes and misprints.
counterclockwise. Swing the latch
1
backwards or sideways .
3
back. Allow the latch
3
by turning clockwise. Fold the
1
3
2
2
1
to
2
2
1
19
