- Page 1 User Instructions Lasse standing aid, size 3+4...
-
Page 2: User Manual
User Manual Identification Rehatec® Dieter Frank GmbH In den Kreuzwiesen 35 D-69250 Schönau www.rehatec.com © 2015 Rehatec® Dieter Frank GmbH All rights reserved. 09.2015/ 10 Technical changes and printing errors reserved. Rehatec ® Dieter Frank GmbH - 07.2015/ 05... - Page 3 Supine-Bear „Lasse“ Dear User, We are glad that you decided in favor of a high-quality product from Rehatec Dieter Frank GmbH and would like to thank you for your confidence in our products. „Lasse“ This guide should help you to familiarize yourself with your Supine-Bear and show you how it can be quickly and easily used in different missions of daily life.
-
Page 4: Table Of Contents
..................5.12. Tilting the entire standing system “Lasse”... - Page 5 6. Technical data 6.1. Lasse size 3 / for children and adolescents ............
-
Page 6: Legal Terms
1. LEGAL TERMS 1.1. Intended use The back-restraint is designed for the physiological stabilization of the user. Lasse is available in different sizes. This manual describes: • Size 3 - for children and adolescents - With a maximum user load of 70 kg •... -
Page 7: Responsibility
Alterations, repairs, maintenance work and upgrades of the therapy chair may only be carried out by authorized persons, and only with original spare parts and accessories. Rehatec’s warranty applies only when the product is used according to the specified conditions and for the intended purposes (see also „Warranty and Service“). -
Page 8: Safety
Depending on the disease pattern and weight, 1-2 assistants are needed to lift the patient to the right position on the Lasse. In case of defects of the Supine-Bear, it may not be used. All repair works may only be carried out by Rehatec® Dieter Frank GmbH or by au-thorized dealers. Rehatec ®... - Page 9 Supine-Bear „Lasse“ Do not apply force during setup the device (for instance height adjustment), otherwise may occur damage of the device due to improper handling. If necessary, read the manual. The screw connections of the foot plates are hand-tightened in the delivery condition! Only after the foot plates have been adapted to the patient's foot, the screws are firmly tightened.
-
Page 10: Product And Delivery Overview
3. PRODUCT AND DELIVERy OVERVIEW 3.1. Delivery Content Typically, the Lasse is delivered fully assembled and pre-adjusted to the child by the authorized supplier. Lasse is available in different sizes. For more information on the size and permissible weight, please refer to the table in the "Technical data" section. -
Page 11: Accessories
Please check your delivery for completeness and integrity. In case of damage or incomplete deli- very, please contact our customer service 4. PREPARING THE DEVICE Please follow the below listed steps before transferring the child onto the Supine-Bear “Lasse”! • Locking the caster wheels (Chapter 5.2) • Releasing the lateral trunk supports (Chapter .5) •... -
Page 12: Device Settings
User Manual 5. PREPARING THE DEVICE Before using the Supine-Bear “Lasse” you have to adjust it to the body measurements of the child! Variable positioning through multi-functional adjustment of height, depth and tilt angle, provides safe supine positioning as well as interactive, supported vertical standing. Flexible leg rests, divided in three interconnected parts, allow easy individual adjustment to accommodate possible contractures of the leg musculature. -
Page 13: Headsupport
Supine-Bear „Lasse“ 5.2. Kopfstütze The headrest is adjustable in height, depth and tilt. Pay attention to hazards of jamming and crushing. The maximum adjustment is achieved when the pipe end is flush with the guid . Height adjustment Loosen wing screw Move head support to desired height. -
Page 14: Armrest
Körpermaße des Kindes anpassen. Pay attention to hazards of jamming and crushing. Height adjustment Loosen both locking lever at the back. Push the complete backrest into the desired position. Fasten both locking lever again. Rehatec ® Dieter Frank GmbH - 07.2015/ 05... -
Page 15: Lateral Trunk Supports (Optional)
Supine-Bear „Lasse“ Furthermore, it is possible to offset the position of the back support by means of its screwed connection by a grid. Loosen the screws . If necessary, loosen the two clamping levers and move the backrest upwards, then tighten the clamping lever again. -
Page 16: Pelvic Supports
Pay attention to hazards of jamming and crushing. Unfold Pull the locking pin down. The pelvic supports can now be folded outwards. The locking pin locks automatically. Rehatec ® Dieter Frank GmbH - 07.2015/ 05... -
Page 17: Height Adjustment
Supine-Bear „Lasse“ Re-folding the pelvic supports Pull the locking pin down. Cymbal pad and attach to the basin. Lock the locking bolts Height adjustment Loosen wing screw at the back. Adjust pelvic support to desired Height. Fasten wing screw again. -
Page 18: Leg Supports
User Manual 5.7. Leg supports The leg supports of the Supine-Bear “Lasse” can be adjusted in various ways such as in general height, general angle and knee angle. Pay attention to hazards of jamming and crushing. General Height adjustment Loosen wing screw and locking lever at the back. -
Page 19: Anatomic Knee Blocks
Supine-Bear „Lasse“ 5.8. Anatomic Knee blocks The optionally available knee blocks control the position of the knees. Höhe, Winkel, Neigung und Spreizung sind individuell anpassbar. Pay attention to hazards of jamming and crushing. The maximum adjustment is achieved when the pipe end is flush with the guid . -
Page 20: Footrest, Divided
User Manual 5.9. Individual footplates Two footplates belong with the Supine-Bear “Lasse”. They should be adjusted to the needed height of the user‘s feet. The various adjustment options allow for adjustment of foot length and ankle position as well as for consideration of therapeutic goals (e.g. correction of pes equinus where accessories available). -
Page 21: Tray (Optional)
Supine-Bear „Lasse“ Pes equinus correction (optional) The screw connections of the foot plates are hand-tightened when delivered! Only after the foot plates have been adapted to the patient's foot, the screws should be firmly tightened. Use an Allen key (size 5) to loosen the screws on the ball joint below the foot plates. -
Page 22: Seat Belt Systems
All belts and positioning means must be in the correct position and fastened. Belts may not be twisted. Check the belts at regular intervals. Positioning means and belts should be tightened so as to ensure adequate security for the user without compromising on comfort. Rehatec ® Dieter Frank GmbH - 07.2015/ 05... - Page 23 Supine-Bear „Lasse“ Butterfl y chest harness The chest harness off ers multiple adjustment options. The following steps describe the easiest way to open the harness and position the child comfortably. Opening and Closing Open or close the zipper completely. If necessary, open the snap-in buckles by pushing them in or push them in and snap them into place.
-
Page 24: Tilting The Entire Standing System "Lasse
User Manual 5.12. Hydraulic tilt of the entire Supine-Bear “Lasse” The Supine-Bear “Lasse” has a hydraulic tilt mechanism which is operated by the hand lever at the head rest. The device must be positioned with sufficient clearance. No persons or objects are allowed in the swivel range - danger of collision! Pay attention to hazards of jamming and crushing. -
Page 25: Hand Switch Operation
Before you can adjust the standing aid, it must be connected to the power supply. (See chapter "Commissioning the drive") With the help of the hand switch, the Lasse can be sleeplessly adjusted. Select "UP" or "DOWN". Hold down the button and place the patient in the desired position. -
Page 26: Startup Of The Drive Without Battery
The device should then be ready for operation again. Connect the device to the power supply by plugging the mains plug into a mains socket (220 V). Rehatec ® Dieter Frank GmbH - 07.2015/ 05... -
Page 27: Battery Powered Accessories
Supine-Bear „Lasse“ 5.16. Battery powered accessories The assembly and disassembly of the parts and cables may only be carried out in a voltage-free state. Mounting / connecting battery Screw the support plate to the support plate Insert the battery into the holder by snapping it into place. -
Page 28: Angle Adjustment Without Battery Power
The battery is only used as an emergency power supply. The mains connection should always be produced as much as possible. Connect the device to the power supply by plugging the mains plug into a mains socket (220 V). Rehatec ® Dieter Frank GmbH - 07.2015/ 05... -
Page 29: Battery Use And -Operations
Supine-Bear „Lasse“ 5.18. Battery use and -operations As long as the control is supplied with the mains voltage, the automatic charging circuit ensures a permanent operational readiness. After a network-dependent use of the device, the rechargeable battery should be recharged immediately by restoring the mains connection. -
Page 30: Technical Data
User Manual 6. TECHNICAL DATA 6.1. Lasse size 3 - For children and adolescents • Max. user weight: 70 Kg • For body size: 135 cm - 165 cm Frame dimensions: • Dimensions: Height: 1.60 m, Width: 70 cm • Material: steel / aluminum frame with 75 mm wheels •... -
Page 31: Control System
Supine-Bear „Lasse“ Type/Model DEWERT MEGAMAT MCZ (MEGAMAT 2 6000) Drive type Single drive Adjustment speed without load to 6,2 mm/s operating temperature +10°C to +40°C (+50°F to +104°F) rel. Humidity from 30% to 75% Air pressure from 700 hPa to 1060 hPa Betriebshöhe... -
Page 32: Product Identifi Ation
In den Kreuzwiesen 35 D-69250 Schönau manufacturer Tel. 06228 - 9136 -0 Fax 06228 - 9136 -99 Product size Product Type Lasse size 1 / 2 / 3 / 4 Produkt / Typ Maximum permissible Max. Belastung 60 70 weight... -
Page 33: Type Signs
Supine-Bear „Lasse“ 7.1. Type Signs Mark of conformity Mark of conformity Recycling-Symbol Operating equipment with protection class II according to IEC / EN 60601-1 Electrical appliances are not included in household waste only for use at dry areas Heat protection with15A / 32V / FK1... -
Page 34: Care And Maintenance
• In case of complaints or problems, please contact your local dealer. • Moving parts / mechanisms can be treated with a Teflon spray (dry lubricant). Use soft cloth to remove excess of lubricant. Rehatec ® Dieter Frank GmbH - 07.2015/ 05... - Page 35 Supine-Bear „Lasse“ • The Lasse should be checked every twelve months with consideration of the previously performed maintenance intervals. The maintenance table should be filled out by the dealer. • Unauthorized alterations or changes to the drive system are not permitted for safety reasons.
-
Page 36: Reuse
10. DISPOSAL / RECyCLING This product must not be disposed of with normal domestic waste. For the Supine-Bear „Lasse“ proper disposal should be carried out. For this purpose please contact your dealer. Packaging materials must be separated according to their types of waste and must be disposed in the waste containers according to municipality policy of sorting and recycling. -
Page 37: Warranty And Service
Warranty extends to defects of the product as result of provable flows of material or workmanship. A three year warranty is provided for all frame parts of the Supine-Bear “Lasse”. Defect parts will be repla-ced free of cost. The manufacturer will not take responsibility in the case that constructive intervention and changes have taken place, which exceed the device‘s adjustability in regard to the... - Page 38 The below identified ehatec product is of perfect quality and functional construction. Any damage as a result of material defects will be remedied free of cost by Rehatec within a three year time frame, starting with the date of purchase.
- Page 39 Notes Rehatec ® Dieter Frank GmbH In den Kreuzwiesen 35 D-69250 Schönau + 49 (0) 6228 - 91 36 0 + 49 (0) 6228 - 91 36 99 www.rehatec.com info@rehatec.com...
- Page 40 Rehatec ® Dieter Frank GmbH In den Kreuzwiesen 35 D-69250 Schönau + 49 (0) 6228 - 91 36 0 + 49 (0) 6228 - 91 36 99 www.rehatec.com info@rehatec.com Rehatec ® Dieter Frank GmbH - 07.2015/ 05...
