Internal Call - ELCOM RER1 X Series Manual

Individual call push-
button address/function
Automatic call push-
button addressing
Door speaker
volume
Microphone
sensitivity
Operating sig-
nal sound volume
Door release
unlocking time
Door release
function
set
door address
Camera present
Call push-button
Backlighting settings
(switch-on brightness
level)
Display error codes
(max. 5 can be saved)
Reset error codes
factory setting
2) Door station call-free door-opening function only possible in single door systems.
Figure 11: Overview of system settings
4 Elcom Kommunikation GmbH-Zum Gunterstal-66440 BLIESKASTEL-GERMANY - www.elcom.de -
Confirm the call push-
button to be set
= Cancel Addressing executed/can-
celled,
= Start addressing
... Volume set,
is displayed
Default setting
Sensitivity set.
...
is displayed
Default setting
...
Volume set,
= Acoustic signal off
is displayed
Default setting
Unlocking time set,
... Seconds
is displayed
Default setting seconds
= only with door call
Door release function is set,
= also without door call
2)
is displayed
Default setting
x ... x
x = received line Door address set,
address
is displayed
Default setting
= No camera
= with camera Camera option set,
Default setting: Audio is displayed
Video
...
= Off
= lowest value Backlighting set,
= highest value is displayed
= always on
Default setting
... Error codes
= communication module
Error codes were displayed,
= sticking call button
is displayed
= module address
= no error present
= Cancel Error codes were deleted,
= Reset is deleted
Reset to the factory setting, in-
= Cancel
= Reset dication goes out
... = Call push-button address
= Light push-button
= Door release push-button
= no function
i
is displayed
1) Requires the appropriate default setting by
Address/Function
saved,
is displayed

Internal call

:
1)
In the door communication system,
internal calls from indoor station to
indoor station are possible. Unlike
comfort indoor stations only the fixed
addresses and are available
as call destination for the internal call.
the installer (see: Indoor station/Expanded
settings).
