DEMO MANUAL DC1698A

PARTS LIST

ITEM QUANTITY
General BOM
1
2
3
DC1698A-A
1
2
3
DC1698A-B
1
2
3
DC1698A-C
1
2
3
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE
2 C1, C2
1 C3
1 R2
1 DC1698A
1 R1
1 U1
1 DC1698A
1 R1
1 U1
1 DC1698A
1 R1
1 U1
DESCRIPTION
Capacitor, 0.1μF 10% 25V X7R 0603
Capacitor, 100pF 10% 16V X7R 0402
Resistor, 0Ω 0603 1% 1/16W
General BOM
Resistor, 0.05Ω 1% 2512 2W
IC, LT1999IMS8-10
General BOM
Resistor, 0.025Ω 1% 2512 1W
IC, LT1999IMS8-20
General BOM
Resistor, 0.01Ω 1W 1% 2512 SMD
IC, LT1999IMS8-50
MANUFACTURER'S PART NUMBER
AVX, 06033C104KAT2A
AVX, 0402YC101KAT2A
YAGEO, RC0603FR-070RL
SEI, CSRN2512FT50L0
Linear Technology, LT1999IMS8-10#PBF
Vishay, WSL2512R0250FEA
Linear Technology, LT1999IMS8-20#PBF
Vishay, WSL2512R0100FEA
Linear Technology, LT1999IMS8-50#PBF
dc1698afa
