Summary of Contents for Advantech UBX-110H
- Page 1 User Manual UBX-110H 8K UHD Fanless Mini Box PC...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
-
Page 3: Product Warranty (2 Years)
Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation. -
Page 4: Technical Support And Assistance
Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –... -
Page 5: Packing List
Before system installation, check that the items listed below are included and in good condition. If any item does not accord with the list, contact your dealer immediately. 1 x UBX-110H unit 1 x Power adapter (DC 12V, 60W) ... -
Page 6: Safety Instructions
70 dB (A). The equipment should only be installed in a restricted access area. DISCLAIMER: These instructions are provided according to IEC 704-1 stan- dards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. UBX-110H User Manual... -
Page 7: Consignes De Sécurité
FSP/ FSP060-DAAN2) suitable for use at TMA 60 °C (140 °F) min., and the out- put is rated 12 V , 5.0A min., ES1. If you need further assistance, contact Advantech for additional information. Consignes de Sécurité Veuillez lire attentivement ces instructions de sécurité. - Page 8 L'équipement ne doit être installé que dans une zone d'accès restreint. AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclarations contenues dans ce. Ce modèle est destiné à être alimenté par une alimentation certifiée UL (adapta- teur: FSP/FSP060-DAAN2), adaptée à...
-
Page 9: Table Of Contents
Chapter Hardware Installation ......5 Introduction ....................6 UBX-110H I/O Connectors................ 6 Figure 2.1 UBX-110H Front View ..........6 Figure 2.2 UBX-110H Rear View..........6 Hardware Installation ................7 2.3.1 Memory, M.2 SSD, and Wi-Fi Module Installation ......7 VESA Mounting Kit Installation ..............9 Figure 2.3 UBX-110H VESA Installation........ - Page 10 UBX-110H User Manual...
-
Page 11: Chapter 1 General Information
Chapter General Information... -
Page 12: Introduction
1.1 Introduction The Advantech UBX-110H is an ultra-compact box PC that is used for offices, retail applications, etc. It features an 11th Gen Intel® processor to boost system perfor- mance and efficiency. The UBX-110H enables 8K video resolution via USB-C output that delivers vivid and high-quality A/V experiences. -
Page 13: Mechanical Specifications
1.3 Mechanical Specifications 1.3.1 System Dimensions 1.3.2 Weight 0.94 kg UBX-110H User Manual... -
Page 14: Power Requirements
Lithium: 3V/220 mAh 1.5 Environmental Specifications 1.5.1 Temperature Operating Temperature: 0 ~ 40°C (If the UBX-110H operating temperature is up to 45°C, please use a power adapter with a temperature spec that is compli- ant.) Storage Temperature: -20 ~ 60°C ... -
Page 15: Chapter 2 Hardware Installation
Chapter Hardware Installation... -
Page 16: Introduction
2.1 Introduction The following sections introduce the I/Os on the UBX-110H and demonstrate the memory, storage, and Wi-Fi module installation. 2.2 UBX-110H I/O Connectors Figure 2.1 UBX-110H Front View Figure 2.2 UBX-110H Rear View UBX-110H User Manual... -
Page 17: Hardware Installation
2.3 Hardware Installation 2.3.1 Memory, M.2 SSD, and Wi-Fi Module Installation Please follow these steps to install the memory and M.2 SSD for the UBX-110H. Remove the specified 6 screws. After removing the 6 screws, please remove the bottom cover. You will see one DDR4 memory slot, two SSD slots, and one Wi-Fi module slot under the shield- ing cases, respectively. - Page 18 Please use a tool to help remove the shielding case without breaking it. a) In the memory slot, please add the DDR4 memory and stick the thermal pads inside and on top of the shielding case. UBX-110H User Manual...
-
Page 19: Vesa Mounting Kit Installation
Users can select an appropriate installation. Figure 2.3 UBX-110H VESA Installation Please follow these steps to install the UBX-110H VESA mounting kit with thermal isolation. Please remove the four footpads from the bottom cover of the UBX-110H. After removing the foot pads, go on to the next step. - Page 20 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. ©Advantech Co., Ltd. 2024...
