- Page 1 Keyless User Guide Connected DO NOT FIT KEYLESS UNTIL DOOR INSTALLATION IS COMPLETE. PLEASE READ THE INSTRUCTIONS BEFORE USING KEYLESS. YD-01-CON-UG Rev. 001...
- Page 2 This new Smart Lock uses the latest technology to make your life easier This user manual enables you to operate the product safely and to its full potential. Please ensure you read it completely before using the Yale Keyless Connected Smart Lock Keyless Helpline:...
-
Page 3: Table Of Contents
CONTENTS Introduction Safety Precautions Product Features Getting Started Lock Overview Set/Change Master Code Set/Delete User Code Set One Day Codes Register/Delete RFID Cards/Tags Register/Delete Key Fobs Change Re-lock Time Auto Re-lock on/off Volume setting Smart Home Connecting to a Home Automation System Operating the lock Unlocking the door Extra Features... -
Page 4: Safety Precautions
Safety Precautions Please read this carefully Caution Make sure to follow the above instructions to avoid any injuries or damage to the product . -
Page 5: Product Features
By adding the corresponding module, your Keyless lock can be integrated with your home automation system. Key Fob Entry (Optional) Up to 5 Yale key fobs can be assigned to allow the lock to be unlocked remotely. RFID Card/Tag Entry The door can be unlocked using a Mifare(TM) RFID Card... -
Page 6: Lock Overview
Back (Battery Pack) Handing Plate DO NOT FIT KEYFREE UNTIL DOOR INSTALLATION IS COMPLETE. PLEASE READ THE INSTRUCTIONS BEFORE USING KEYFREE. KFCON-UG Rev. 001 Installation Guide User Guide ¨ Optional Accessories Key Fob Home Automation Yale Nightlatch (Optional) Module (Optional) - Page 7 Lock Overview Front (Front Body, install on the outside of the door) (Front Body, installed on the outside of the door) Keypad (10-Key) * Button Thumb Turn Reset Button Low Battery indicator # Button Emergency Power Supply Terminal Back (Back Body, installed on the inside of the door) Slot for RF Module(Optional) R Button 4 x 1.5V AA Alkaline Batteries...
- Page 8 Changing Master Code Registration The master code is the main password to the lock. As well as allowing entry through the door, it is also used to configure the lock including adding and removing users. Step Icon Expected Feedback Description Keypad will illuminate Touch the Keypad with the Touch the Keypad to...
- Page 9 Setting a User Code The lock can hold up to 20 unique user codes, each one has a slot in the locks memory from 1 to 20. If a new code is written to a slot that already holds a code it will overwrite it. Because of this it is important to record which codes are stored in each slot.
- Page 10 Deleting a User Code To stop a user having access their code will need to be deleted. Before doing this you will first need to know which slot in the locks memory their code is in. Please see the user code log at the back of the guide. Step Description Icon...
- Page 11 Setting a One Day Code The one day code is a code that will automatically expire after 24 hours. This allows short term access to be granted to someone. Icon Description Expected Feedback Step Touch the Keypad to begin Touch the Keypad with the Keypad will illuminate palm of your hand followed by 2 tone beep...
- Page 12 Adding an RFID Card/Tag The lock can hold up to 20 RFID cards or tags, each one has a slot in the locks memory from 1 to 20. If a new card/tag is written to a slot that already holds a tag it will overwrite it. Because of this it is important to record which cards/tags are stored in each slot.
- Page 13 Deleting an RFID Card/Tag To delete a previously added tag follow the instructions below. Icon Expected Feedback Description Step Touch the Keypad with the Keypad will illuminate Touch the Keypad to begin. palm of your hand followed by 2 tone beep If you have forgotten the master code please Enter the master code, 2 tone beep...
- Page 14 Register Key Fob Yale key fobs allow you to open the lock at a distance of up to 15 meters. This requires both the Yale key fob and the corresponding lock module to work. Up to 12 key fobs can be registered on 1 lock, and like the user codes they each have their unique slot in the lock memory.
- Page 15 Delete Previously Paired Key Fob If a key fob is lost or stolen it can be removed from the lock so that it can no longer be used to open it. Step Expected Feedback Description Touch the Keypad with the Touch the Keypad to begin.
-
Page 16: Change Re-Lock Time
Change PIN R e-lock Time e-lock The r time is the amount of time it takes for the external handle to disengage after the lock has been unlocked with a correct PIN. The default is 7 seconds. Icon Step Expected Feedback Description Touch the Keypad with the Keypad will illuminate... -
Page 17: Auto Re-Lock On/Off
Auto Re-lock On/Off The lock can be toggled between two modes. With auto re-lock mode on the lock will automaticallyre-lockafter the configured re-lock time. With auto re-lock mode off the lock will not re-lock until the keypad is awoken by placing your palm on Step Expected Feedback Description... - Page 18 Volume Mode The lock can be toggled between three volume modes. In silent mode only programming beeps will be heard. In quite mode the keypad beeps will be quieter, in loud mode they will be loud. Step Expected Feedback Description Icon Touch the Keypad with the Keypad will illuminate...
-
Page 19: Smart Home
Smart Home Lock Module The Yale Keyfree lock can have a removable wireless communication module within the lock. This module is used for all wireless communications to both home automation systems and key fobs. In order to connect to a home automation system a new module may be required for the lock, however changing the module has the potential to disrupt the current wireless communications. -
Page 20: Connecting To A Home Automation System
Smart Home Connecting to a Home Automation System Connecting to a home automation system is a two way process and may require the home automation system to be configured to look for a new device, please consult the manual that came with the system for more information. Step Description Icon... - Page 21 Smart Home Disconnecting from a Home Automation System For security reasons a lock will not connect to a new home automation system if it is linked to another. If you have changed your home automation system please run through the disconnecting settings before adding the new one. Step Icon Expected Feedback...
- Page 22 Opening the lock with a PIN code Step Expected Feedback Description Icon Touch the Keypad with the Keypad will illuminate Touch the Keypad to begin palm of your hand followed by 2 tone beep Enter a valid user code The Thumb turn is now engaged and will 3 tone ascending beep followed by the * key allow you to open the door.
-
Page 23: Extra Features
Extra Features Intrusion Alarm The alarm sound continues for 30 minutes or until it is disarmed. Damage Alarm : An alarm will sound if the outer unit is disconnected from the inner. -
Page 24: Incorrect Pin Lockout
Extra Features Incorrect PIN Lockout For security if the wrong PIN is entered 5 consecutive times the lock will lockout for 3 minutes. This is indicated by the number 3 on the keypad flashing. To Release Lockout Method Press the [R] button inside of battery cover. Press any key fob button... -
Page 25: Emergency Power
Emergency Power Emergency Power Supply for Discharged Batteries If the batteries in the lock have completely failed emergency power can be provided by a 9V battery on the front body. To Supply Emergency Power Step Icon Description Place 9V battery onto the emergency power supply terminal Contact the 9V battery Touch the keypad with the palm of your hand... - Page 26 Resetting the Lock In the event of losing the master code to the lock, the lock will need to be reset back to factory default settings. This will mean that all previously configured user codes, key fobs, RFID tags, and home automation systems will stop working. It will also result in the master code being set to the factory default which is ‘123456’...
- Page 27 Specifications Specifications Contact Details Keyless Helpline: 01902364606 Email: smartlocks@yale.co.uk Website: www.yale.co.uk...
- Page 28 Please keep your proof of purchase safe, this must be submitted when making a claim under this guarantee. Please note that it is a condition of this guarantee that your Yale product: Yale installation and maintenance instructions provided to you at the time of purchase.
-
Page 29: User Code Log
User Code Log Pin Codes Slot Number Name Pin Code (Optional) -
Page 30: User Rfid Card/Tag Log
User RFID Card/Tag Log Pin Codes Slot Number Name Card/Tag Number... -
Page 31: Key Fob Log
Key Fob Log Key Fob Slot Number Name...
