Figure 7 shows the STDC14 connector (CN8) pinout.
Table 5 describes the STDC14/MIPI10 debug connector (CN8) pinout.
STM32 pin
-
VDD
GND
GND
-
-
PA10
1. PA15 is used by default for the UCPD_CC1 feature. To use PA15 for JTDI, add the R42 resistor. In this case, the
UCPD_CC1 feature cannot be used.
UM2617 - Rev 7
Figure 7. STDC14 connector (CN8) pinout
Table 5. STDC14 connector pinout
Board function
-
Power
Power
Power
KEY
GNDDetect: Pull-down
T.VCP_RX: Target RX used
for VCP (can be a UART
supported bootloader)
Pin Pin Board function
1 2
T.SWDIO: Target SWDIO
using SWD protocol or target
3 4
JTMS (T.JTMS) using JTAG
protocol
T.SWCLK: Target SWCLK
using SWD protocol or target
5 6
JCLK (T.JCLK) using JTAG
protocol
T.SWO: Target SWO using
SWD protocol or target JTDO
7 8
(T_JTMS) using JTAG
protocol
(1)
T.JTDI : Not used by SWD
protocol, target JTDI (T.JTDI)
9 10
using JTAG protocol, only for
external tools
NRST: Target NRST using
11 12 SWD protocol or target JTMS
(T.JTMS) using JTAG protocol
T.VCP_TX: Target TX used
13 14 for VCP (can be a UART
supported bootloader)
UM2617
Embedded STLINK-V3E
STM32 pin
- -
PA13
PA14
PB3
(1)
PA15
NRST
PA9
