- Page 1 INSTALLATION & MAINTENANCE GUIDE LOW VOLTAGE LANDSCAPE LIGHTING ® Core Drill Well Light ® ITEM: AWL-5012 1-813-978-3900 • Mon-Fri 9am-6pm (EST) - 1 -...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Core Drill Well Light - AWL-5012 ® IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Fixture Body B. (1) PVC tube PARTS REQUIRED (SOLD SEPARATELY) A. (1) MR11 Lamp PRODUCT DIMENSIONS 2.17” 5.19” 5.87” 1.85” 813.978.3900 • customersupport@amplighting.com • www.amplighting.com...
- Page 4 INSTALLATION & MAINTENANCE GUIDE Core Drill Well Light - AWL-5012 ® REMOVE GLARE GUARD Unscrew the glare guard to remove it from the fixture body. Glare Guard Fixture Body ADJUST SOCKET HEIGHT To get more or less glare PUSH protection, push the socket...
- Page 5 INSTALL GLARE GUARD Thread the glare guard back onto the fixture body and hand tighten until snug. Glare Guard Fixture Body DIG HOLE PVC Tube Dig hole in the ground. Ground Make sure there is approximately 3” of space surrounding the PVC tube 3”...
- Page 6 INSTALLATION & MAINTENANCE GUIDE Core Drill Well Light - AWL-5012 ® WIRE CONNECTION Pass fixture supply cable Fixture through the PVC tube. Body Place the fixture body onto the PVC tube properly. Strip both leads from PVC Tube the fixture supply cable and the main supply cable.
- Page 7 FILL PEA GRAVEL OR SAND Install the PVC tube with PVC Tube with Fixture fixture in hole and fill hole Pea Gravel with pea gravel or sand. INSTALL/REPLACE LAMP Reverse steps 3 - 4 to remove the glare guard to expose the MR11 lamp and replace it with the correct wattage and type marked on the fixture label.
- Page 8 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, AMP® Lighting, Lutz FL USA 33549 • All rights reserved. customersupport@amplighting.com • amplighting.com...
