- Page 1 INSTALLATION & MAINTENANCE GUIDE LOW VOLTAGE LANDSCAPE LIGHTING ® Micro Dot LED Light ® ITEM: AHS-7022 1-813-978-3900 • Mon-Fri 9am-6pm (EST) - 1 -...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Micro Dot LED Light - AHS-7022 ® IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
-
Page 3: Package Contents
PACKAGE CONTENTS A. (1) Fixture Body B. (1) PC Tube PRODUCT DIMENSIONS Fixture Body PC Tube 1.44” 1.38” 1.3” 1.26” 1” DIG HOLE AND FILL GRAVEL ON THE BOTTOM Dig a 1.76” diameter, 2.38” PC Tube deep hole in the ground. 1/4”... -
Page 4: Wire Connections
INSTALLATION & MAINTENANCE GUIDE Micro Dot LED Light - AHS-7022 ® WIRE CONNECTION Pass the fixture supply cable from the fixture Fixture Body body through the PC tube. Strip both leads from fixture supply cable. PC Tube Using two UL listed... - Page 5 INSTALL FIXTURE BODY Push the fixture body into the Fixture Body PC tube until the flange of fixture body is flush to the top of the PC tube. PC Tube 813.978.3900 • customersupport@amplighting.com • www.amplighting.com...
- Page 6 INSTALLATION & MAINTENANCE GUIDE 813.978.3900 • customersupport@amplighting.com • www.amplighting.com...
- Page 7 813.978.3900 • customersupport@amplighting.com • www.amplighting.com...
- Page 8 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, AMP® Lighting, Lutz FL USA 33549 • All rights reserved. customersupport@amplighting.com • amplighting.com...
