TUBING

Color-Coded Two-Stop Tubing

Color-coded stops provide easy tube identification and create a uniform tension in the pump for high
accuracy and repeatability.
• Precision extruded to tight tolerances for high repeatability and accuracy.
• Extension tubing can be connected using straight fittings, barbed fittings, or by splicing.
• Flared ends are available for select materials, which aid in making connections (NOTE: Flared ends
require special connections for correct operation).
Color-Coded Stops
ORANGE/BLACK
ORANGE/RED
ORANGE/BLUE
ORANGE/GREEN
ORANGE/YELLOW
ORANGE/WHITE
BLACK/BLACK
ORANGE/ORANGE
WHITE/WHITE
RED/RED
GREY/GREY
YELLOW/YELLOW
YELLOW/BLUE
BLUE/BLUE
GREEN/GREEN
PURPLE/PURPLE
PURPLE/BLACK
PURPLE/WHITE
BLACK/WHITE
2-13 Masterflex Ismatec Multichannel Peristaltic Pumps
® ®
Tube ID (mm) Ismatec Size
0.13 -9
0.19 -10
0.25 -12
0.38 -14
0.51 -18
0.64 -22
0.76 -24
0.89 -26
1.02 -28
1.14 -30
1.33 -32
1.42 -34
1.52 -36
1.65 -38
1.85 -40
2.03 -42
2.29 -44
2.79 -48
3.17 -49
IPC 45 RPM
Min Flow Rate Max Flow Rate
mL/min mL/min
0.0016 0.16
0.0027 0.27
0.0041 0.41
0.0090 0.90
0.0155 1.55
0.0237 2.37
0.0331 3.31
0.0450 4.50
0.0572 5.72
0.0695 6.95
0.0900 9.00
0.1063 10.63
0.1227 12.27
0.1431 14.31
0.1759 17.59
0.2127 21.27
0.2577 25.77
0.3641 36.41
0.4500 45.00
IPC 11.25 RPM
Min Flow Rate Max Flow Rate
mL/min mL/min
0.00039 0.039
0.00066 0.068
0.00099 0.101
0.00220 0.225
0.00380 0.388
0.00580 0.593
0.00810 0.828
0.01100 1.125
0.01399 1.431
0.01700 1.738
0.02200 2.250
0.02599 2.658
0.03000 3.068
0.03499 3.579
0.04300 4.398
0.05200 5.318
0.06300 6.443
0.08899 9.101
0.11000 11.25
