K K K K K K K
C OOKER HOOD
INSTRUCT ON MANUAL
Read this manual carefully before operation
Pictures in this manual are for reference only, the product in kind prevail.
I
MH60A4300B-ES
MH90A4300B-ES
MH60A4300W-ES
MH90A4300W-ES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH60A4300B-ES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Midea MH60A4300B-ES

  • Page 1 K K K K K K K C OOKER HOOD INSTRUCT ON MANUAL Read this manual carefully before operation Pictures in this manual are for reference only, the product in kind prevail. MH60A4300B-ES MH90A4300B-ES MH60A4300W-ES MH90A4300W-ES...
  • Page 2: Recommendations And Suggestions

    RECOMMENDATIONS AND SUGGESTIONS The instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION  The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.
  • Page 3 COMPONENTS Ref. Qty. Product Components Hood Body, complete with: Controls, Light, Blower, Filter. Lower Decorative Chimney ( optional ) Upper Decorative Chimney ( optional ) Flange ( optional ) Exhaust Pipe The Activated Charcoal filter ( optional ) Qty . Ref.
  • Page 4 DIMENSIONS 600/897 Min. Min. 530mm 530mm...
  • Page 5: Installation

    INSTALLATION WALL DRILLING AND BRACKET FIXING (OPTIONAL) Optional As a first step, proceed with the following drawings:  A vertical line up to the ceiling or up to the upper limit, at the center of the area in which the hood is to be fitted.
  • Page 6: Ducted Version Air Exhaust System

     Mark a point (3) on the horizontal line C, 130 (250 optional) mm to the right of the vertical reference line.  Repeat this operation on the other side, checking that the two marks are on the same horizontal line.
  • Page 7: Chimney Assembly

    CHIMNEY ASSEMBLY The chimney can only be installed with exhausting hood. Lower Decorative Chimney  Fix a Chimney fixing bracket 21 onto the Lower Decorative Chimney with 2 screws 12 (4.2 x 9.5) supplied with the hood.  Slightly widen the two sides of the flue and hook them onto the hood body, making sure that they are well seated.
  • Page 8 Button Function Remarks Turns the lighting system on or off. Button on. Decrease the motor speed. When are on. When the fan is running. Display fan gear "1、2、3、b". Display "0". Delayed shutdown mode, or standby mode. Increase the motor speed. When are on.
  • Page 9: Grease Filters

    MAINTENANC GREASE FILTERS CLEANING METAL SELF-SUPPORTING GREASE FILTERS  The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher.  Pull the comfort panels to open them. ...
  • Page 10: Light Replacement

    LIGHTING LIGHT REPLACEMENT 1.5W LED light. Switch off the extractor hood and isolate the extractor hood by pulling out the  mains plug or switching off the fuse. Remove the grease filter.  Remove the light by levering its fitting from the hood body(this may require ...
  • Page 11: Troubleshooting

    TROUBLE SHOOTING Fault Cause Solution The blades are blocked. The capacitor is damaged. Replace capacitor. Light on, but The motor is damaged. Replace motor. motor does not The internal wiring of motor is cut off/ work Replace motor. disconnected. An unpleasant smell may be produced.
  • Page 12 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood.
  • Page 13: Campana Extractora

    CAMPANA EXTRACTORA K K K K K K K MANUAL DE INSTRUCCIONES Lea este manual cuidadosamente antes de manipular el artefacto Las imágenes de este manual son referenciales, prevalece el tipo de producto. MH60A4300B-ES MH90A4300B-ES MH60A4300W-ES MH90A4300W-ES...
  • Page 14: Recomendaciones Y Sugerencias

    RECOMENDACIONES Y SUGERENCIAS Las instrucciones de uso se aplican a varias versiones de este artefacto. Por consiguiente, puede encontrar descripciones de características individuales que no se aplican en su artefacto en específico. INSTALACIÓN El fabricante no se hace responsable por los daños resultantes de una instalación incorrecta o negligente.
  • Page 15 COMPONENTES Ref. Cantidad Componentes del Producto Cuerpo de la Campana, completo con: Controles, Luz, Soplador, Filtro. C h i m e n e a d e c o r a t i v a i n f e r i o r (opcional) C h i m e n e a d e c o r a t i v a s u p e r i o r (opcional)
  • Page 16 DIMENSIONES 600/897 Mín. Mín. 530mm 530mm...
  • Page 17: Instalación

    INSTALACIÓN PERFORACIÓN DE PARED Y FIJACIÓN DE SOPORTES (OPTIONAL) Opcional Elija un modo de ventilación: Una línea vertical hasta el techo o hasta el límite superior, en el centro de la zona en donde se instalará la campana. Una línea horizontal A a 1320 - 1700 mm por encima de la superficie de la cocina. Una línea horizontal B a un mínimo de 926 mm por encima de la superficie de la cocina.
  • Page 18 Marque un punto (3) en la línea horizontal C, 130 (250 opcional) mm a la derecha de la línea de referencia vertical. Repita esta operación al otro lado, verificando que las dos marcas estén en la misma línea horizontal. Fije los soportes (opcional): Perfore los puntos marcados (1) (2) (3) con una broca de ɸ10 mm.
  • Page 19 CONJUNTO DE CHIMENEA La chimenea solo se puede instalar con campana extractora. Chimenea Decorativa Inferior Fije un soporte de fijación de la chimenea 21 en la chimenea decorativa inferior con 2 tornillos 12 (4,2 x 9,5) proporcionados con la campana. Ensanche ligeramente los dos lados de la chimenea y engánchelos al cuerpo de la campana, asegurándose de que estén bien colocados.
  • Page 20 Botón Función Observaciones E n c i e n d e o a p a g a e l s i s t e m a d e Botón de encendido. iluminación. C u a n d o e s t á n Disminuye la velocidad del motor.
  • Page 21: Mantenimiento

    MANTENIMIENTO FILTROS DE GRASA LIMPIEZA DE FILTROS DE GRASA METÁLICOS Los iltros deben limpiarse cada 2 meses de operación, o más seguido si el uso es particularmente intenso, y pueden lavarse en un lavavajillas. Tire de los paneles frontales para abrirlos. Retire los filtros uno a uno empujándolos hacia la parte posterior de la unidad de campana y al mismo tiempo jale hacia abajo.
  • Page 22 ILUMINACIÓN REEMPLAZO DE LA LUZ Luz LED de 1,5W. Apague la campana extractora y aísle la campana extractora desenchufando la fuente de alimentación o desconectando el fusible. Retire el filtro de grasa. Retire la luz haciendo palanca en el accesorio del cuerpo de la campana (es posible que sea necesario aplicar presión o fuerza para esta acción).
  • Page 23: Solución De Problemas

    SOLUCIÓN DE PROBLEMAS Fallo Causa Solución Las cuchillas están bloqueadas. El condensador está dañado. Reemplace el condensador. Luz encendida, El motor está dañado. Reemplace el motor. pero el motor no funciona El cableado interno del motor está cortado/ desconectado. Puede producirse un olor Reemplace el motor.
  • Page 24 El fabricante declinará toda responsabilidad si las recomendaciones e instrucciones anteriormente indicadas sobre la instalación, mantenimiento y uso no han sido observadas y respetadas para el uso de la campana extractora. P/N:16173000A19207...
