INOXPA OVERFLOW VALVE Installation, Service And Maintenance Instructions page 9

V74
Product family
V74
INOXPA S.A.U.
10.207.30.07EN · (0) 2023/11
0 0 - 00 06
Material
06
Connection
00 welded/welded
10 male/welded
11 male/male
77 clamp/clamp
Standard pipe
0 DIN
1 OD
Type
0 standard
1 manual
Overflow valve 74700
52 050 06
Tared
03 0 - 300 kPa (0 - 3 bar)
06 0 - 600 kPa (0 - 6 bar)
10 0 - 1000 kPa (0 - 10 bar)
Size
025 DN 25, OD 1''
032 DN 32
040 DN 40
045 OD 1½''
050 DN 50, OD 2''
063 OD 2½''
065 DN 65
076 OD 3''
080 DN 80
Seals
52 EPDM
70 PTFE/FPM
78 FPM
1.4404 (AISI 316L)
Installation
9
