9.9. EXPLODED DRAWING AND PARTS LIST OF THE OVERFLOW VALVE 74700 PTFE SEAT
SEAL
Position
01 body
05 shaft seal
06 external spring
06A internal spring
08 shaft
08A shaft sleeve
11 guide bushing
12 body cover
12A spring cover
19 flat seal
20B O-ring
20C O-ring
25 spring washer
26C top nut
26F lock nut
34 clamp
45 elastic ring
1) recommended spare parts
26
45
08A
20C
19
08
Description
1
1
1
1
1
26C
26F
11
06
06A
25
12A
05
12
20B
01
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
34
Material
1.4404 (AISI 316L)
FPM
1.4310 (AISI 302)
1.4310 (AISI 302)
1.4404 (AISI 316L)
1.4404 (AISI 316L)
Iglidur G
1.4404 (AISI 316L)
1.4307 (AISI 304L)
PTFE
FPM
FPM
1.4037 (AISI 304L)
1.4037 (AISI 304L)
1.4037 (AISI 304L)
1.4301 (AISI 304)
1.4021 (AISI 420)
