9.10. EXPLODED DRAWING AND PARTS LIST OF THE OVERFLOW VALVE 74700 WITH
HANDLE AND PTFE SEAT SEAL
Position
01 body
04 handle
05 shaft seal
06 spring
08 shaft
08A shaft sleeve
12 body cover
12A spring cover
19 flat seal
20B O-ring
20C O-ring
22D top screw
25 spring washer
26C top nut
26F lock nut
34 clamp
45 elastic ring
50A ping
1) recommended spare parts
INOXPA S.A.U.
10.207.30.07EN · (0) 2023/11
45
08A
20C
19
08
Description
1
1
1
1
04
50A
22D
26C
26F
06
25
12A
12
05
20B
01
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Technical Specifications
34
Material
1.4404 (AISI 316L)
1.4307 (AISI 304L)
FPM
1.4310 (AISI 302)
1.4404 (AISI 316L)
1.4404 (AISI 316L)
1.4404 (AISI 316L)
1.4307 (AISI 304L)
PTFE
FPM
FPM
bronze
1.4037 (AISI 304L)
1.4037 (AISI 304L)
1.4037 (AISI 304L)
1.4301 (AISI 304)
1.4021 (AISI 420)
A2
27
