Hardware Installation and Reference Guide
Front Panel
Figure 1-2 Front Panel of RG-SF2920-8GT2MG2XS
Remarks
1. System status indicator
2. Console port
3. Optical port indicator
4. SFP/SFP+ port
Side Panel
Figure 1-3 Side Panel of RG-SF2920-8GT2MG2XS
5. 1G/2.5GBase-T adaptive Ethernet port indicator
6. 1G/2.5GBase-T adaptive Ethernet port
7.
10/100/1000Base-T
indicator
8. 10/100/1000Base-T adaptive Ethernet port
3
Product Introduction
adaptive
Ethernet
port
