BluStream HEX70ARC-KIT Quick Reference Manual

Introduction

FEATURES:
• Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
• Extends HDMI 1080p up to a distance of 70m over a single CAT cable
• Features 1 x HDMI loop-out on HEX70ARC-TX for integrating local displays or cascading to multiple devices
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports ARC (Audio Return Channel) from connected display via HDMI ARC or optical digital input*
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Bi-directional IR pass-through
• Supplied with Blustream IR receiver and emitter
• Supports bi-directional PoC (Power over Cable) to power extenders from either transmitter or receiver end
• HDCP 2.2 compliant with smart EDID management
* Please note: When using an eARC display, only 2 channel PCM audio is supported.
01
HEX70ARC-KIT
Quick Reference Guide
The HEX70ARC-KIT 4K HDBaseT™ ARC extender set offers market leading features
for the custom installation industry. The product delivers HDMI, ARC, Optical Audio
Return, Bi-directional IR and Bi-directional PoC up to lengths of 70m.
|
