- Page 1 HEX70B-RX HEX70B-TX HEX70B-RX/TX User Manual...
- Page 2 Cat5e/6/6a cabling with or in close par- allel proximity to mains power cables. Do not substitute or use any other power supply other than the enclosed unit, or a Blustream approved re- placement. Do not disassemble either the Trans- mitter or Receiver units for any reason.
- Page 3 • Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0) • Supplied with Blustream IR receiver and emitters • Supports all industry standard video resolutions including • Supports bi-directional PoH (Power over HDBaseT™) to...
- Page 4 HEX70B-KIT HEX70B User ManUal USER MANUAL Panel Description HEX70B-RX HEX70B-Rx Receiver HDMI indicator HDBaseT connection indicator HDMI output HDBaseT input IR Receiver jack (Sensor input) IR Transmitter jack (Emitter output) Power indicator DC power input Panel Description HEX70B-TX HEX70B-Tx Transmitter...
- Page 5 HEX70B HEX70B-KIT User ManUal USER MANUAL CONNECTION DIAgRAM contact support@blustream.com...
- Page 6 NOTE: Specifications are subject to change without notice. Weight and dimensions are approximate. Package Contents: Maintenance Clean this unit with a soft, dry cloth. Never use • HEX70B-Rx* alcohol, paint thinner or benzene to clean this unit. • 1 x 12V/2A DC power supply • 1 x IR Emitter •...
