Page 1: User Manual
HDMI LINK LINK Coaxial HDMI in IR RX IR TX HDMI Out Audio IR RX IR TX Audio Out LINK Power LINK Power Input Input RS232 HDBT Out DC12V RS232 HDBT In DC12V Select Select HEX100HDVGA-KIT User Manual Revision 2_01-2017... -
Page 2: Panel Descriptions
Do not substitute or use any other power supply other than the enclosed unit, or a Blustream approved replacement. Do not disassemble either the Transmitter or Receiver units for any reason. Doing so will void the manufacturer’s warranty. - Page 3 • Built in audio breakout with DAC on HDBaseT receiver • Manual switching between inputs using toggle button or RS232 control on either Blustream Transmitter or Receiver • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission •...
- Page 4 HEX100HDVGA-KIT USER MANUAL Panel Description HEX100HDVGA-TX HEX100HDVGA HDMI LINK Power LINK Input HDMI in IR RX IR TX Audio RS232 HDBT Out DC12V Select VGA input RS-232 / serial connector Analogue Left/Right audio input - 3.5mm stereo jack Input select button - switch between HDMI and VGA/...
- Page 5 The Power link light will be on when power is connected directly to the Transmitter or is being received from the Receiver unit Blustream Support department are on hand to assist with signal distribution issues should they arise - please email us at one of the email addresses below.
-
Page 6: Rs232 Control
HEX100HDVGA-KIT USER MANUAL RS232 Management The HEX100HDVGA can pass-through an RS232 signal for control of 3rd party equipment connected to either side of the TX and RX units. The HEX100HDVGA can also be set to receive an RS232 signal at either TX or RX end for the switching of the HDMI and VGA inputs on the Transmitter unit. - Page 7 The Blustream range of HDBaseT products include multiple options for control and routing of IR. IMPORTANT: Blustream Infrared products are all 5v and NOT compatible with alternative manufacturers Infrared solutions. When using third party 12v IR control solutions please use supplied Blustream IRCAB cable for IR conversion (sold separately).
- Page 8 HEX100HDVGA-KIT USER MANUAL www.blustream.co.uk...
-
Page 9: Specifications
• 2 x Mounting bracket sets • 1 x HEX100HDVGA-TX • 1 x User manual • 1 x Mounting bracket set Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. contact support@blustream.co.uk / support@blustream.com.au... - Page 10 www.blustream.com.au...
