TASKING iSystem Cypress CYT2B9 Hardware User Manual page 15

P2: Power supply configuration
Emulation Adapter Power supply is configured via the unshrouded 26-pin 2.54 mm header
(P2).
Signal direction
Target board
Target board
Not Connected
Target board
Target board
Target board
Not Connected
Not Connected
Not Connected
Not Connected
Ground
Ground
Ground
Signal Direction is described from the BlueBox perspective.
By default, all jumpers are set to connect your target power supply to the microcontroller resid-
ing on the Emulation Adapter . Only pins 1-2, 3-4, 7-8, 9-10 and 11-12 must be bridged but for
the convenience and ease of use all jumpers are set, except for pins 5-6 and 25-26.
Pin 26 is the polarizer key preventing incorrect connection of the IEA-PS Power converter, when
being plugged in.
If a different power source is used (e.g. a Standalone operation), remove all jumpers and apply
3V3 or 5V to:
·
CVDDA (pin 2),
·
CVREFH (pin 4, apply the same voltage as on VDDA),
·
CVDDIO_1 (pin 8),
·
CVDDIO_2 (pin 10),
·
CVDDD (pin 12).
Enclosed Power supply package (Power converter and Power adapter) simply plugs into the P2
header row, providing the necessary power supply for Emulation Adapter operation.
LED D1 indicates, if power is supplied to the Emulation Adapter. Refer to the microcontroller doc-
umentation for more details about power voltage designations.
P3 – P6: Emulation device pinout
P3, P4, P5, P6 pinouts match the pinout of the emulation device (176QFP). Refer to the micro-
controller documentation for pin assignment.
J14 and J15: GND connecting points
J14 and J15 provide grounding points on the EA.
Signal Pin
VDDA 1
VREFH 3
NC 5
VDDIO_1 7
VDDIO_2 9
VDDD 11
NC 13
NC 15
NC 17
NC 19
GND 21
GND 23
GND 25
P2 Signal description
Pin Signal
2 CVDDA
4 CVREFH
6 NC
8 CVDDIO_1
10 CVDDIO_2
12 CVDDD
14 NC
16 NC
18 NC
20 NC
22 GND
24 GND
26 KEY
Signal direction
Emulation device
Emulation device
Not Connected
Emulation device
Emulation device
Emulation device
Not Connected
Not Connected
Not Connected
Not Connected
Ground
Ground
