Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Wiring diagram
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) Ignition: Green
D2D Port
(+) Ignition Input/Output
(+) Starter Output
(+) Accessory Output
(+) 12V Input
(AC) Tach Input
(-) Ground
(-) Hood Input
(-) Parking Lights Output
6 403.HONDA7 2.43 2019 Honda CR-V
©2022 VOXX•DEI LLC. All rights reserved.
Ignition Switch
(white conn.)
or Blue, pin 2 (+) 12V: Green
2 1
5 4 3
(+) Accessory:
(+) Starter:
Orange or White,
Yellow, pin 5
pin 4
Hood Pin
Headlight Switch
(white 12-pin conn.)
6 5 4 3 2 1
12 11 10 9 8 7
(-) Parking Lights:
Gray, pin 8
or White , pin 1
F-CAN High:
OBDII
Diagnostic 1
Connector
9
F-CAN Low:
HS CAN High 2: Tan/Black: 3
HS CAN High 1: Orange/Green: 5
HS CAN Low 1: Orange/Brown: 6
Ignition Interrupt (vehicle side): Yellow: 8
Ignition Interrupt (connector side): Orange/Yellow: 9
(AC) Tach Output: Violet/White: 5
Immobilizer Data: Yellow/Black: 10
Immo. Data: Pin 2
Ignition Interrupt: Pin 6
Cut
6 5
7
B-CAN Low:
Blue, pin 5
Pin 6
8
16
Pin 14
HS CAN Low 2: Tan: 4
Immobilizer Control Unit
(gray 7-pin conn., right of
steering column under ignition switch)
4 2 1
B-CAN High:
Pink, pin 4
).
XKD2D65
