- Page 1 DC-F20 Document Camera User Manual - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Package Contents ..............2 Chapter 2 Product Function Descriptions ..........3 Chapter 3 Installation and Connections ..........4 3.1 Document Camera Size .................... 4 3.2 Connecting to a computer ..................5 3.3 Connecting to an Interactive Whiteboard (IWB) ..........5 3.4 Installing Application Software ................ -
Page 3: Chapter 1 Package Contents
Chapter 1 Package Contents DC-F20 USB 2.0 cable, 1.8 M (Type-C to Type-A) -
Page 4: Chapter 2 Product Function Descriptions
Chapter 2 Product Function Descriptions Turn on/off Microphone LED indicator Auto Tune (Press and hold for 2 seconds to switch to Rotate) LED indicator USB Type C port Kensington Fixed lock hole lock hole Items Function... -
Page 5: Chapter 3 Installation And Connections
Chapter 3 Installation and Connections 3.1 Document Camera Size Length x Width x Height: Storage compartment: 265 x 65 x 24 mm Display: 150 x 65 x 404.75 mm Weight: 310 g * Please only operate in the extended angles as illustrated. Improper usage may damage the machine. -
Page 6: Connecting To A Computer
USB Cable USB Cable Computer 3.4 Installing Application Software The Lumens Ladibug software installed on the computer enables you to: Control DC-F20 Capture and record images Annotate the image, highlight important details and save it Support the full screen function. -
Page 7: Chapter 4 Start Using
5. You are ready to teach/present. * Please download Ladibug software from Lumens website * When connected to a computer via a USB cable, DC-F20 can also be used with video software, such as Skype and Zoom. -
Page 8: Chapter 5 Descriptions Of Major Functions
Chapter 5 Descriptions of Major Functions 5.1 Control the Camera 1. Please download Lumens Ladibug software at Lumens website. 2. Please refer to Ladibug Software User Manual for software-related functions. 5.2 Use Skype for Video Conference Please refer to Chapter 3 Installation and Connections to finish connecting the computer. -
Page 9: Chapter 6 Troubleshooting
Chapter 6 Troubleshooting This chapter describes problems you may encounter while using DC-F20. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. -
Page 10: Chapter 7 Safety Instructions
Chapter 7 Safety Instructions English Always follow these safety instructions when setting up and using this Product: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Do not block the slots and openings in the case of the product. - Page 11 Français Respectez toujours les instructions de sécurité lors de la configuration et de l’utilisation de la Document Camera : 1 Opération 1.1 Veuillez utiliser le produit dans l’environnement d’exploitation recommandé, à l’écart de l’eau ou d’une source de chaleur. 1.2 N’installez pas le produit sur une position inclinée ou sur un chariot, un support ou une table instable. 1.3 Ne pas bloquer les orifices et ouvertures du boî...
-
Page 12: Supplier's Declaration Of Conformity 47 Cfr § 2.1077 Compliance Information
Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：DC-F20 Model Number：Document Camera Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules. -
Page 13: Copyright Information
Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
