- Page 1 DC-F80 4K Document Camera User Manual - English [Important] To download the latest versions of the Quick Start Guide, multilingual user manual, software, driver, etc., please visit Lumens https://www.MyLumens.com/support...
-
Page 2: Table Of Contents
Machine Size ..................... 10 Installation and setup ................10 Connect to a projector, monitor or HDTV (HDMI mode) ......11 Connect to a computer and use Lumens™ software (USB Mode) ..11 Installing Application Software ..............12 Chapter 5 Start Using ................... 13 Direct Use (HDMI Mode) ................ - Page 3 I would like to adjust the brightness ............16 I would like to rotate the image ..............16 I would like to enlarge a part of the image ..........17 Chapter 8 DIP Switch Setting ..............18 Description of DIP ..................18 Resolution Switch ..................
-
Page 4: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 5: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Always follow these safety instructions when using the product: Operation Please use the product in the recommended operating environment, away from water or source of heat. Do not place the product on a tilted or unstable trolley, stand or table. Please clean the dust on the power plug prior to usage. -
Page 6: Chapter 2 Package Contents
Chapter 2 Package Contents Quick Installation DC-F80 USB cable (USB 2.0) Guide English... -
Page 7: Chapter 3 Product Overview
Chapter 3 Product Overview 3.1 Overview Lens/Lamp Control panel LED Indicator 3.2 Extension angle Support Arm <Note> Please only operate in the extended angles as illustrated. Improper usage may damage the machine. English... -
Page 8: Precautions For Operation
3.3 Precautions for Operation <Note> When moving the device, do not grasp the front of the lens or the body. Please use both hands to hold the bottom of the device. Handling the device improperly may cause machine malfunction. 3.4 I/O functions Introduction Front View Back... -
Page 9: Description Of Led Indicator
Kensington safety Lock hole of safety lock lock Press the button for initialization to reset to Reset button original factory settings Adjust the resolution setting. The default is 1920*1080/30 fps DIP Switch Setting To switch the setting, please refer to Chapter 8 DIP Switch Setting Mode Switch Button... -
Page 10: Relative Position Of The Presenter And Document
3.6 Relative position of the presenter and document Projector Computer English... -
Page 11: Chapter 4 Installation And Connections
Chapter 4 Installation and Connections 4.1 Machine Size Length x Width x Height: Extended - 306 x 140 x 373 mm Closed - 137 x 140 x 270 mm Weight: 1.2 kg 4.2 Installation and setup Please set up the DIP switch setting first. Refer to Chapter 8 DIP Switch Setting. -
Page 12: Connect To A Projector, Monitor Or Hdtv (Hdmi Mode)
4.3 Connect to a projector, monitor or HDTV (HDMI mode) HDMI cable Monitor Projector HDTV 4.4 Connect to a computer and use Lumens™ software (USB Mode) Projector USB cable HDMI cable Computer <Remark>Please download the relevant software from Lumens website. -
Page 13: Installing Application Software
Annotate the image, highlight important details and save it. Support the full screen function. <Note> Please download the relevant software from the Lumens website. For installation steps and software operation, please refer to the Ladibug™ 4K software user manual. -
Page 14: Chapter 5 Start Using
5. You are ready to teach/present. 5.2 Use with Ladibug (USB Mode) 1. Switch to USB mode, and use a USB cable to connect DC-F80 and the computer Open Ladibug, click to open [Search Window], and select... - Page 15 3. You can start using DC-F80 English...
-
Page 16: Chapter 6 Introductions To Control Panel Buttons
Chapter 6 Introductions to Control Panel Buttons Icon Function Descriptions Power on and off Short press: Power on (under standby) Press and hold for 1 second: Power off (under power on) Press and hold for 10 seconds: Forcibly power off the system Automatically adjust the image to have the best brightness and focusing performance Auto Tune... -
Page 17: Chapter 7 Descriptions Of Major Functions
Chapter 7 Descriptions of Major Functions 7.1 I would like to automatically adjust the image to have the best brightness and focusing performance Press [Auto Tune] for the best brightness and focusing performance. 7.2 I would like to freeze the live image ... -
Page 18: I Would Like To Enlarge A Part Of The Image
7.7 I would like to enlarge a part of the image 1. Press to activate the partial enlarged mode. 2. Press [], [], [], or [] to move and view the partial enlarged images. 3. Press to exit the partial enlarged mode. English... -
Page 19: Chapter 8 Dip Switch Setting
Chapter 8 DIP Switch Setting 8.1 Description of DIP Function Descriptions DIP1 & DIP2 Output Resolution OFF (Normal mode): 30/25 fps, applicable to general DIP3 scene ON (High-speed mode): 60/50 fps, applicable to support rapidly changing scene (Only applicable to 1080P) DIP4 ：60Hz ON：50Hz... -
Page 20: Chapter 9 Troubleshooting
Chapter 9 Troubleshooting This chapter describes problems you may encounter while using DC-F80. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. -
Page 21: S Upplier's Declaration Of Conformity 47 Cfr § 2.1077 Compliance Information
Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：DC-F80 Model Number：4K Document Camera Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules.
